Каталог запасных частей к технике: SDLG LG952. STEERING UNIT ASSEMBLY
/38.gif)
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4120001419 | STEERING UNIT BZZ1-800 | |
| 2 | 4011000479 | BOLT | |
| 3 | 4011000473 | BOLT | |
| 4 | 29310011191 | MOUNTING FRAME | |
| 5 | 4120001855 | STEERIGN COLUMN LG20-ZXZ-09 | |
| 6 | 4120000018 | STEERINGWHEEL | |
| 7 | 4041000564 | JOINT | |
| 8 | 4041000783 | O-RING | |
| 9 | 29200008201 | FLOW PIPE TO RADIATOR | |
| 10 | 4030000026 | O-RING | |
| 11 | 4041000043 | FLANGE | |
| 12 | 4011000475 | BOLT | |
| 13 | 29200008211 | FLOW PIPE FROM RADIATOR | |
| 14 | 4120001768 | WASHER | |
| 15 | 4011000400 | BOLT M27x1.5x50 | |
| 16 | 2080900036 | FLOW PIPE FROM MONOSTABTLE VALVE | |
| 17 | 4041000758 | TUBE LGB128-010070 | |
| 18 | 4030000090 | 0-RING 28.0x2.65G | |
| 19 | 29190008741 | CONNECTER | |
| 20 | 4120000017 | MONOSTABTLE VALVE FLD-F60-H | |
| 21 | 4011000049 | BOLT GB5782-M10x55EpZn-8.8 | |
| 22 | 4015000025 | Washer | |
| 23 | 29200007901 | CONNECTER | |
| 24 | 4041000132 | CONNECTOR LGB120-02220 | |
| 25 | 4013000007 | NUT | |
| 26 | 4015000162 | Washer | |
| 27 | 4011000528 | BOLT GB16674-M10x100EpZn-8.8 | |
| 28 | 29310011301 | ADJUSTING SEAT | |
| 29 | 29310011251 | MOUNTING PLATE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
