Каталог запасных частей к технике: SDLG LG952. DUMP CYLINDER (371401)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Позиция на иллюстрации Заводской номер детали Название детали
1 4021000050 JOINT BEARING GB9163-GE50ES-2RS
2 4120001326003 HOLD DOWN PLATE
3 4120001326002 PISTON ROD
4 4120001326004 CYLINDER COVER
5 4120001326001 SEALING MEMBER AGGREGATE
6 4120001326001 SEALING MEMBER AGGREGATE
7 4120001326001 SEALING MEMBER AGGREGATE
8 4120001326001 SEALING MEMBER AGGREGATE
9 4014000147 BOLT GB70.1-M12x45EpZn-10.9
10 4015000026 WASHER
11 4120001326001 SEALING MEMBER AGGREGATE
12 4120001326005 CYLINDER BODY
13 4120001326001 SEALING MEMBER AGGREGATE
14 4120001326006 PISTON
15 4120001326001 SEALING MEMBER AGGREGATE
16 4120001326001 SEALING MEMBER AGGREGATE
17 4120001326007 BUSH
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
