Каталог запасных частей к технике: SDLG LG952. 4RD SHAFT (I)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
20
21
22
23
24
25
26
26
27
27
27
27
28
28
28
28
29
29
30
31
31
31
32
32
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
Позиция на иллюстрации Заводской номер детали Название детали
1 4021000020 BEARING
2 4013000036 NUT
3 4015000008 WASHER
4 3030900136 INTER-INPUT SHAFT
5 4021000011 BALL BEARIN
6 4015000015 RIONG SNAP
7 3030900138 ISOLATED BUSHING
8 3030900157 SPRING
9 3030900166 PIN
10 3030900165 ISOLATED WASHER
11 3030900155 ROLLER
12 3030900164 INNER RACE CAM
13 3030900167 BOLT
14 3030900137 OUT RACE GEAR
15 4021000018 BEARING
16 3030900169 ISOLATED WASHER
17 3030900168 ISOLATED BUSHING
18 4015000017 RIONG SNAP
19 3030900139 PISTION
20 3030900143 EXTERNAL SEAL RING
21 3030900163 INTERNAI SEAL RING
22 3030900170 BOLT
23 4015000036 WASHER
24 3030900162 STOP WASHER
25 3030900160 REVERSE PLANET SPINDLE
26 3030900147 SPACER
27 3030900154 RIONG SNAP
28 4090000001 ROLLER
29 3030900148 PLANET
30 3030900171 CARRIER OF REVERSE ASSY
31 3030900140 REVERSE FIRST SPEED DRIVEN DISK
32 2030900028 REVERSE FIRST SPEED DRIVE DISK
33 3030900141 SPRING
34 3030900176 PIN
35 3030900161 ROUND PIN
36 2030900029 ISOLATED BRACKET
37 3030900142 SPRING PIN
38 3030900158 REVERSE RANGE GEAR-RING
39 3030900156 RIONG SNAP
40 3030900151 CARRIER OF THE FIRST RANGE PLANET GEAR
41 3030900149 FIRST SPEED PLANET SPINDLE
42 3030900150 LOCK PLATE
43 3030900153 GEAR-SUN
44 3030900152 CONNECTING DISH FOR THE DIRECT RANGE
45 4015000026 WASHER
46 4011000125 BOLT
47 3030900172 INTERNAL GEAR-RING ASSEMBLY FOR FIRST RANGE
48 3030900144 FIRST RANGE PISTION
49 3030900113 SEALING RING
50 3030900145 CYLINDER-HOUSING FOR THE FIRST RANGE
51 3030900146 SQUARE SEAL
52 3030900159 MOUNTING PLATE
53 4021000019 BEARING
54 4015000024 RETAINNER RING
