Каталог запасных частей к технике: SDLG LG946L. ELECTRIC SYSTEM
1
1
2
2
3
3
3
3
3
4
5
6
7
7
8
9
9
9
10
11
12
13
14
15
16
21
22
22
23
50
50
51
51
51
51
52
52
52
52
53
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 26370002451 | Cable sleeve | |
| 2 | 4011000461 | BOLT | |
| 3 | 29370016801 | BATTERY WlRE P50x1900 | |
| 4 | 29370016141 | BATTERY WlRE P50x450 | |
| 5 | 4130000427 | POWER SWITCH K01K18-A | |
| 6 | 29370016151 | BATTERY WlRE A50x550 | |
| 7 | 26370002441 | Cable sleeve | |
| 8 | 4130000057 | BATTERY | |
| 9 | 4190000020 | CLIP | |
| 10 | 26370001911 | CLAMP | |
| 11 | 4130000009 | ELECTRIC HORN | |
| 12 | 4011000152 | BOLT | |
| 13 | 4130000542 | LEFT FRONT HEAD LAMP | |
| 14 | 4130000543 | RIGHT FRONT HEAD LAMP | |
| 15 | 29370016011 | FRONT FRAME WlRE | |
| 16 | 4130000329 | PRESS SWITCH | |
| 17 | 4130000910 | PRESSURE SWlTCH YK210B | |
| 18 | 29040008901 | CONNECTOR | |
| 19 | 4130000278 | DISSEPIMENT PRESSURE SWITCH310-LGK | |
| 20 | 29370016031 | PANEL HARNESS ASSEMBLY | |
| 21 | 29370016021 | REAR BODY WlRlNG HARNESS | |
| 22 | 4130000213 | REAR LAMP | |
| 23 | 4130000121 | Buzzer | |
| 24 | 4130000544 | REAR LARGE LAMP SPH4-1031 | |
| 25 | 29370009331 | COVER HARNESS | |
| 26 | 4130000797 | FORWARD LlGHTlNG QZD-2 | |
| 27 | 29370016042 | PANEL ZL2-235M | |
| 28 | 4130000208 | STARTING SWITCH 08086-10000 | |
| 29 | 4130000912 | Relay | |
| 30 | 4130000290 | STEERING SWITCH | |
| 31 | 29370012571 | SUPPORTING PLATE | |
| 32 | 4014000026 | SCREW | |
| 33 | 4015000207 | WASHER | |
| 34 | 29370012561 | FIXED PEDESTAL | |
| 35 | 29370012551 | PIPE NIP | |
| 36 | 4011000481 | BOLT | |
| 37 | 4130000869 | Relay | |
| 38 | 4130000496 | CAP | |
| 39 | 4130000499 | SPRAY WATER BUTTON-SWITCH | |
| 40 | 4130000917 | SWlTCH,REAR HEADLlGHT K931-02HDD | |
| 41 | 4130000555 | FRONT BlG LAMP BUTTON-SWlTCH JK931-01QDD | |
| 42 | 4130000491 | Rocker switch | |
| 43 | 4130000490 | Rocker switch | |
| 44 | 4130000489 | BACK LAMP BUTTON-SWlTCH JK931-01BGD | |
| 45 | 4130000492 | Rocker switch | |
| 46 | 4130000493 | Rocker switch | |
| 47 | 4130000498 | SIDE FRAME | |
| 48 | 4130000497 | Switch panel | |
| 49 | 4130000060 | HAND BRAKE SWITCH | |
| 50 | 4130000643 | Bulb | |
| 51 | 4130000618 | Bulb | |
| 52 | 4130000916 | Bulb | |
| 53 | 4130000915 | Bulb | |
| 54 | 4130000620 | Bulb |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
