Каталог запасных частей к технике: SDLG LG944MSK. Hydraulic control assembly

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
4
4
5
5
5
5
5
5
5
5
5
5
6
7
8
9
10
11
11
11
12
12
12
12
12
12
13
13
13
14
15
15
15
15
16
16
16
16
16
17
17
17
17
17
17
17
18
19
20
20
21
21
22
23
24
25
26
27
27
27
28
28
28
29
30
31
31
31
32
33
34
35
36
36
37
38
39
39
40
40
40
40
41
42
43
44
45
46
47
48
48
49
50
51
52
53
53
54
54
55
55
56
57
58
58
59
60
61
62
63
64
65
66
66
66
66
67
67
68
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
83
84
85
86
87
88
89
90
91
Позиция на иллюстрации Заводской номер детали Название детали
1 29120025281 Hose
2 4011000366 BOLT
3 29120015221 WASHER
4 4041000150 STAIGHT JOINT
5 4041000767 O-RING
6 4011000488 BOLT
7 4120002027 PILOT VALVE
8 29120015911 COVER PS
9 4014000058 SCREW
10 29120025291 Hose
11 4041000604 JOINT
12 29120014931 WASHER
13 4011000344 BOLT
14 4041000532 TUBE
15 4041000056 FLANGE
16 4030000029 O-RING
17 4011000475 BOLT
18 29120019351 Pipe
19 4011000556 U-BOLT
20 4015000162 Washer
21 4013000007 NUT
22 29120019271 Anchor plate
23 4011000197 BOLT
24 4015000186 WASHER
25 4011000056 BOLT
26 4011000057 BOLT
27 4015000168 WASHER
28 4013000011 NUT
29 4120002304 Control valve
30 29120016301 PIPE
31 29120007651 JOINT
32 4041001061 PIPE
33 4041001189 HOSE
34 4041001047 CONNECTOR
35 4030000530 O-RING
36 29120015401 FITTING
37 4041000027 FLANGE
38 4041000716 DUST-PREVENTION CAP
39 29120007671 CLAMP
40 4011000458 BOLT
41 4011000477 BOLT
42 29120011391 STEADY REST
43 26370001961 Clamp
44 29120016311 PIPE
45 29120016321 PIPE
46 29120016331 PIPE
47 29120016341 PIPE
48 4011000447 BOLT
49 29120016021 PLATE
50 4041000576 PIPE
51 29120015081 JOINT
52 4030000276 O-RING
53 4041001023 JOINT
54 4030000240 O-RING
55 4120001954 STRAINER
56 29120004041 TWO-WAY MASS
57 4120005063 Valve
58 4011000473 BOLT
59 4041000613 PIPE
60 29120010801 RETURN PIPE OF TRANSITION BLOCK
61 29120011471 RETURN PIPE OF SELECTOR VALVE
62 4015000256 WASHER
63 4011000105 BOLT
64 29120010771 MOUNTED PLATE
65 29120010791 TRANSITION BLOCK
66 4041000774 PLUG
67 4030000026 O-RING
68 4041000043 FLANGE
69 4041000731 PIPE
70 4041001301 PIPE
71 29120016351 MOUNTED PLATE
72 29120016741 CLAMP
73 29120016951 MOUNTED PLATE
74 4011000493 BOLT
75 4011000560 BOLT
76 29120015431 CLAMP
77 4041001188 CUSHION
78 4041000869 CUSHION
79 4015000072 WASHER
80 4013000033 NUT
81 29120015711 CLAMP
82 4041000010 FLANGE
83 4030000130 O-RING
84 29120010691 FEEDING TUBE OF MULTIPLE UNIT VALVE
85 4011000479 BOLT
86 4041000958 U-BOLT
87 29120016541 TUBE
88 4011000478 BOLT
89 4011000793 BOLT
90 4011000751 Screw
91 4120001954001 Filter insert
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
