Каталог запасных частей к технике: SDLG LG938L. HYDRAULIC CONTROL ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
8
9
9
9
9
9
9
9
9
9
10
11
11
11
12
12
12
12
12
12
12
13
13
13
14
15
15
16
16
16
17
17
17
17
18
19
20
21
22
23
24
25
25
25
26
26
26
27
28
29
29
30
31
32
33
34
35
36
37
38
38
38
39
40
41
42
43
44
45
46
46
47
47
48
49
50
51
52
52
53
54
55
56
57
58
58
58
59
60
61
62
63
64
65
66
67
67
68
69
70
71
72
73
73
73
74
74
75
75
83
84
85
86
87
88
Позиция на иллюстрации Заводской номер детали Название детали
1 4011000488 BOLT
2 4120002027 PILOT VALVE
3 29120015911 COVER PS
4 4014000058 SCREW
5 29120016291 FEEDING HOSE OF PILOT VALVE
6 4011000366 BOLT
7 29120015221 WASHER
8 4041000150 STAIGHT JOINT
9 4041000767 O-RING
10 29120010841 FRONT PILOT PTPE
11 4041000604 JOINT
12 29120014931 WASHER
13 4011000344 BOLT
14 4041000532 TUBE
15 4041000056 FLANGE
16 4030000029 O-RING
17 4011000475 BOLT
18 29120004031 TUBE
19 4011000556 U-BOLT
20 4015000162 Washer
21 4013000007 NUT
22 29120011372 MOUNTED PLATE
23 4011000447 BOLT
24 4011000057 BOLT
25 4015000168 WASHER
26 4013000011 NUT
27 4120001054 MULTIPLE UNIT
28 29120016301 PIPE
29 29120007651 JOINT
30 4041001061 PIPE
31 4041001189 HOSE
32 4041001047 CONNECTOR
33 4030000530 O-RING
34 4041000027 FLANGE
35 4041000716 DUST-PREVENTION CAP
36 29120007671 CLAMP
37 4011000458 BOLT
38 4011000477 BOLT
39 29120011391 STEADY REST
40 29120016311 PIPE
41 29120016321 PIPE
42 29120016331 PIPE
43 29120016341 PIPE
44 29120016021 PLATE
45 4041000576 PIPE
46 29120015081 JOINT
47 4030000276 O-RING
48 4120001954 STRAINER
49 29120010751 TWO-WAY BLOCK
50 4011000455 BOLT
51 4120000448 PRESSURE SELECTION VALVE
52 4011000473 BOLT
53 4041001146 PIPE
54 29120010801 RETURN PIPE OF TRANSITION BLOCK
55 29120011471 RETURN PIPE OF SELECTOR VALVE
56 29120010771 MOUNTED PLATE
57 29120010791 TRANSITION BLOCK
58 4041000774 PLUG
59 4041000043 FLANGE
60 4041000769 PIPE LGB107-010110
61 4041001301 PIPE
62 29120016351 MOUNTED PLATE
63 29120016741 CLAMP
64 29120016951 MOUNTED PLATE
65 4011000493 BOLT
66 4041000010 FLANGE
67 4030000130 O-RING
68 29120010691 FEEDING TUBE OF MULTIPLE UNIT VALVE
69 29120016541 TUBE
70 4011000478 BOLT
71 4011000793 BOLT
72 4011000056 BOLT
73 29120015401 FITTING
74 4041001023 JOINT
75 4030000240 O-RING
76 4190000020 CLIP
77 29120015431 CLAMP
78 4041001188 CUSHION
79 4041000869 CUSHION
80 4015000072 WASHER
81 4013000033 NUT
82 29120015711 CLAMP
83 4030000026 O-RING
84 4011000197 BOLT
85 4015000186 WASHER
86 4011000105 BOLT
87 4015000256 WASHER
88 4041000958 U-BOLT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
