Каталог запасных частей к технике: SDLG LG938. HYDRAULIC CONTROL ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
4
5
5
5
6
7
7
8
8
9
9
10
11
12
13
13
13
14
14
14
15
16
17
17
17
17
18
18
18
19
19
19
19
19
19
19
19
19
19
19
20
21
22
23
24
24
25
25
25
25
25
25
26
26
27
28
29
30
31
31
31
32
33
34
34
35
36
37
38
39
40
41
42
43
44
45
46
46
47
48
48
48
48
48
48
48
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
66
66
Позиция на иллюстрации Заводской номер детали Название детали
1 4120000370 MONOLEVER PILOT VALVE DXS-OO
2 4041000532 TUBE
3 4041000056 FLANGE
4 4030000029 O-RING
5 4011000475 BOLT
6 29120004031 TUBE
7 4011000556 U-BOLT
8 4015000162 Washer
9 4013000007 NUT
10 29120011372 MOUNTED PLATE
11 4011000447 BOLT
12 4011000057 BOLT
13 4015000168 WASHER
14 4013000011 NUT
15 4041000592 PIPE LGB125-004055
16 4041001023 JOINT
17 4041000604 JOINT
18 4030000240 O-RING
19 29120014931 WASHER
20 4120001054 MULTIPLE UNIT
21 4041000027 FLANGE
22 4041000716 DUST-PREVENTION CAP
23 29120007671 CLAMP
24 4011000458 BOLT
25 4041000767 O-RING
26 4041000632 PIPE
27 29120010631 OIL RETURN TUBE OF MULTIPLE UNIT VALVE
28 4041000774 PLUG
29 4041000010 FLANGE
30 4030000130 O-RING
31 4011000477 BOLT
32 29120011391 STEADY REST
33 29120010691 FEEDING TUBE OF MULTIPLE UNIT VALVE
34 4041000598 PLUG
35 29120010721 MIDDLE PILOT PIPE
36 4041000636 PIPE
37 29120010731 TWO-WAY NEST OF TUBES
38 4041000613 PIPE
39 4041000043 FLANGE
40 4041000769 PIPE LGB107-010110
41 4030000026 O-RING
42 29120010751 TWO-WAY BLOCK
43 4011000455 BOLT
44 29120010771 MOUNTED PLATE
45 4120000448 PRESSURE SELECTION VALVE
46 4011000279 BOLT GB16674-M10x60EpZn-8.8
47 29120011471 RETURN PIPE OF SELECTOR VALVE
48 4011000344 BOLT
49 29120010291 PIPE FROM SELECTOR VALVE TO TRANSITION BLOCK
50 29120010791 TRANSITION BLOCK
51 29120010801 RETURN PIPE OF TRANSITION BLOCK
52 4041000150 STAIGHT JOINT
53 29120010821 FRONT PILOT PTPE
54 29120010831 FRONT PILOT PTPE
55 4011000056 BOLT
56 29120010851 FRONT PILOT PTPE
57 29120010861 FRONT PILOT PTPE
58 4011000447 BOLT
59 29120014332 RUBBER BUSH
60 29120010891 FRONT PILOT PTPE
61 4041000641 PIPE
62 29120010901 FEEDING HOSE OF PILOT VALVE
63 29120010911 RETURN PIPE OF PILOT VALVE
64 29120015221 WASHER
65 4011000366 BOLT
66 29120007651 JOINT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
