Каталог запасных частей к технике: SDLG LG936L. Steering gear system
1
2
3
3
4
5
6
6
7
7
8
9
10
11
12
13
14
15
16
16
17
17
18
19
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
33
34
34
35
36
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 29200010621 | Steering column | |
| 2 | 29200009671 | Pipe | |
| 3 | 4030000289 | O-RING | |
| 4 | 29200009691 | Pipe | |
| 5 | 26370001921 | CLAMP | |
| 6 | 29370018651 | Clamp | |
| 7 | 4011000461 | BOLT | |
| 8 | 4015000256 | WASHER | |
| 9 | 4013000033 | NUT | |
| 10 | 4041002231 | Hose assembly | |
| 11 | 26370001941 | Clamp | |
| 12 | 4041002279 | Hose assembly | |
| 13 | 4041000133 | Nipple | |
| 14 | 4041000767 | O-RING | |
| 15 | 4190001832 | Cable tie | |
| 16 | 4041001047 | CONNECTOR | |
| 17 | 4030000530 | O-RING | |
| 18 | 4011000054 | BOLT GB5782-M12x120EpZn-8.8 | |
| 19 | 29200010471 | Washer | |
| 20 | 4013000158 | Lock nut | |
| 21 | 29200010631 | Priority valve | |
| 22 | 4041000767 | O-RING | |
| 23 | 4041000774 | PLUG | |
| 24 | 4041002232 | Hose assembly | |
| 25 | 29200010641 | Plate | |
| 26 | 4011000089 | BOLT | |
| 27 | 4015000186 | WASHER | |
| 28 | 4041002230 | Hose assembly | |
| 29 | 29200010651 | Diverter valve | |
| 30 | 4120005053 | Priority valve | |
| 31 | 29200009981 | Plate | |
| 32 | 29200009871 | Rubber plate | |
| 33 | 4030000285 | O-RING | |
| 34 | 4041000084 | CONNECTER | |
| 35 | 4041000088 | CONNECTER | |
| 36 | 4030000276 | O-RING |
