Каталог запасных частей к технике: SDLG LG936L. Lifting cylinder assembly (371368)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
19
20
21
22
23
Позиция на иллюстрации Заводской номер детали Название детали
1 4120000867102 RETAINER
2 4120000867103 PISTON ROD
3 4120000867101 SEALING MEMBER AGGREGATE
4 4014000153 SCREW
5 4015000035 WASHER
6 4120000867101 SEALING MEMBER AGGREGATE
7 4120000867101 SEALING MEMBER AGGREGATE
8 4120000867118 SPCER RING
9 4120000867119 STEEL WIRE RING SNAP
10 4120000867101 SEALING MEMBER AGGREGATE
11 4120000867105 ORIENTED SHEATH
12 4120000867101 SEALING MEMBER AGGREGATE
13 4120000867101 SEALING MEMBER AGGREGATE
14 4120000867101 SEALING MEMBER AGGREGATE
15 4120000867101 SEALING MEMBER AGGREGATE
16 4120000867108 CYLINDER BODY
17 4120000867101 SEALING MEMBER AGGREGATE
18 4120000867101 SEALING MEMBER AGGREGATE
19 4120000867101 SEALING MEMBER AGGREGATE
20 4014000485 Screw
21 4120000867111 PISTON
22 4120000867121 BUSHING
23 4120000867101 SEALING MEMBER AGGREGATE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
