Каталог запасных частей к технике: SDLG LG936L. DIESEL ENGINE ASSY
1
2
2
3
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4110000587 | DIESEL ENGINE ASSEMBLY TD226B-6IG15 | |
| 2 | 4013000028 | NUT | |
| 3 | 4015000207 | WASHER | |
| 4 | 4030000521 | RUBBER TUBE | |
| 5 | 4120000049 | RUBBER TUBE | |
| 6 | 4041000829 | CLAMP | |
| 7 | 4041000876 | BUSH | |
| 8 | 4011000461 | BOLT | |
| 9 | 4120000067 | VALVE-HEATER | |
| 10 | 4017000024 | CLAMP | |
| 11 | 29010013441 | CABLE SHAFT | |
| 12 | 4120000096 | ACCELERATOR PEDAL | |
| 13 | 4011000101 | BOLT | |
| 14 | 4015000035 | WASHER | |
| 15 | 4013000033 | NUT | |
| 16 | 29010006681 | JOINT FORK | |
| 17 | 4016000138 | PIN | |
| 18 | 4016000100 | SPLINT PIN | |
| 19 | 4016000120 | SPLINT PIN | |
| 20 | 29010001071 | BOLT SHAFT | |
| 21 | 4014000020 | SCREW | |
| 22 | 29010009212 | CABLE SHAFT | |
| 23 | 29220001191 | CONNECTOR | |
| 24 | 29010008701 | TUBE PIPE | |
| 25 | 4041001214 | HOSE | |
| 26 | 29010008691 | FITTING OIL RETURN | |
| 27 | 29010000111 | DOUBLE BOLT | |
| 28 | 4013000007 | NUT | |
| 29 | 4015000025 | Washer | |
| 30 | 4011000455 | BOLT | |
| 31 | 29220007571 | BRACKET | |
| 32 | 4120000084 | AIR DYER | |
| 33 | 4120000750 | METAL TUBE | |
| 34 | 29220000171 | WASHER | |
| 35 | 29010006621 | SCREW | |
| 36 | 29010006631 | WASHER | |
| 37 | 4011000236 | BOLT | |
| 38 | 4013000020 | NUT | |
| 39 | 4015000176 | WASHER | |
| 40 | 4015000030 | WASHER | |
| 41 | 29050000101 | SHOCK MOUNT | |
| 42 | 29050000121 | WASHER | |
| 43 | 29010008841 | Nipple | |
| 44 | 4011000081 | BOLT | |
| 45 | 4015000197 | WASHER | |
| 46 | 29010015531 | UP HOOD |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
