Каталог запасных частей к технике: SDLG LG936. MULTIPLE DIRECTIONAL CONTROL VALVE
/24.gif)
1
1
2
2
3
3
4
4
5
5
5
5
6
6
7
7
8
8
9
9
9
9
10
11
12
13
13
13
14
14
14
15
16
16
17
17
17
18
18
18
19
20
21
22
23
24
24
24
25
25
25
26
27
28
29
30
31
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
52
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4120000414001 | WASHER | |
| 2 | 4120000414002 | SPLIT PIN | |
| 3 | 4120000414003 | BUTTON PIN | |
| 4 | 4120000414004 | SPRING SEAT | |
| 5 | 4120000414005 | O-RING | |
| 6 | 4120000414006 | RING SNAP | |
| 7 | 4120000414007 | CLAMP RING | |
| 8 | 4120000414008 | SEAL RING | |
| 9 | 4120000414009 | SLELETON OIL SEAL | |
| 10 | 4120000414010 | SLIDE VALVE OF LIFT ARM | |
| 11 | 4120000414011 | PLUG | |
| 12 | 4120000414012 | O-RING | |
| 13 | 4120000414013 | PLUG | |
| 14 | 4120000414014 | O-RING | |
| 15 | 4120000414015 | BOLT | |
| 16 | 4120000414016 | PLUG | |
| 17 | 4120000414017 | O-RING | |
| 18 | 4120000414018 | CHECK VALVE | |
| 19 | 4120000414019 | SPRING | |
| 20 | 4120000414020 | STEEL BALL | |
| 21 | 4120000414021 | SPRING | |
| 22 | 4120000414022 | SPRING SEAT | |
| 23 | 4120000414023 | POSITION SLEEVE | |
| 24 | 4120000414024 | WASHER | |
| 25 | 4120000414025 | BOLT | |
| 26 | 4120000414026 | SPRING | |
| 27 | 4120000414027 | SLIDE VALVE OF TILT ARM | |
| 28 | 4120000414028 | BOLT | |
| 29 | 4120000414029 | SPRING | |
| 30 | 4120000414030 | PLATE | |
| 31 | 4120000414031 | SPRING SEAT | |
| 32 | 4120000414032 | RETURN SPRING | |
| 33 | 4120000414033 | SPRING SEAT | |
| 34 | 4120000414034 | END COVER | |
| 35 | 4120000414035 | VALVE BODY | |
| 36 | 4120000414036 | WASHER | |
| 37 | 4120000414037 | NUT | |
| 38 | 4120000414038 | WIRED CIRLLIP | |
| 39 | 4120000414039 | SPOOL FOR OIL RETURN | |
| 40 | 4120000414040 | O-RING | |
| 41 | 4120000414041 | PLUNGER | |
| 42 | 4120000414042 | SPRING | |
| 43 | 4120000414043 | MOUNTING PIN | |
| 44 | 4120000414044 | SLEEVE OF RELIEF VALVE | |
| 45 | 4120000414045 | INJECTION RING | |
| 46 | 4120000414046 | WIRED CIRCLIP | |
| 47 | 4120000414047 | SPOOL | |
| 48 | 4120000414048 | SPRING | |
| 49 | 4120000414049 | ADJUST SHIM | |
| 50 | 4120000414050 | SPRING COVER | |
| 51 | 4120000414051 | REGULATING SCREW | |
| 52 | 4120000414052 | WASHER | |
| 53 | 4120000414053 | NUT | |
| 54 | 4120000414054 | LOCKING NUT | |
| 55 | 4120000414055 | SAFETY VALVE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
