Каталог запасных частей к технике: SDLG LG936. STEERING SYSTEM

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
53
Позиция на иллюстрации Заводской номер детали Название детали
1 4041000516 PIPE
2 2920000402 OIL OUTLET TUBE OF STEERING GEAR
3 4030000289 O-RING
4 2920000403 OIL OUTLET TUBE OF STEERING GEAR
5 4120000360 STEERING WHEEL
6 4120000019 STEERING POLE
7 4041000564 JOINT
8 4011000475 BOLT
9 4120001317 STEERING GEAR
10 4041000515 PIPE LGB165012129
11 2920000778 FEEDBACK PIPE OF PRIORITY VALVE
12 4041000131 JOINT
13 2920000825 OIL PIPE OF STEERING GEAR
14 4041000187 JOINT
15 4011000302 BOLT
16 4120000709 PRIORITY VALVE
17 4041000188 JOINT
18 4041000514 PIPE
19 4012000003 DOUBLE-SCREW BOLT
20 4015000168 WASHER
21 4013000011 NUT
22 4120000866 TANDEM GEAR PUMP
23 2911000004 SEALING PLATE OF PUMP
24 2919000412 OUTLET PIPE OF STEERING PUMP
25 4011000475 BOLT
26 4041000026 FLANGE
27 4030000026 O-RING
28 2919000413 0IL-TUBE
29 2919000414 INLET TUBE OF PRIORITY VALVE
30 4041000774 PLUG
31 4041000767 O-RING
32 4041000188 JOINT
33 4030000028 O-RING
34 4011000164 BOLT
35 4041000056 FLANGE
36 2919000405 OIL INLET TUBE OF STEERING PUMP
37 4090000043 OIL INLET PIPE
38 4017000007 CLAMP
39 2921000408 TUBE
40 4030000275 O-RING
41 4011000481 BOLT
42 4011000277 BOLT
43 2921000409 TUBE
44 4041000563 PIPE
45 4120001004 STEERING CYLINDER
46 2921000766 OIL INLET PIPE OF STEERING CYLINDER
47 2921000406 PERMANENT SEAT
48 2921000407 RUBBER PLATE
49 4011000476 BOLT
50 4041000783 O-RING
51 4041000784 O-RING
52 4041000771 O-RING
53 4041000779 O-RING
