Каталог запасных частей к технике: SDLG LG933. Final drive
1
2
3
3
4
5
6
7
7
8
9
10
11
12
13
13
14
15
15
16
17
18
19
20
21
22
29
30
31
32
33
34
35
36
37
37
38
38
39
39
40
40
41
42
42
43
43
43
43
43
43
43
43
44
44
44
44
44
44
44
44
45
45
45
45
46
46
46
46
47
47
47
47
48
48
49
49
50
50
50
51
51
51
52
52
53
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4013000066 | NUT | |
| 2 | 3050900007 | WASHER | |
| 3 | 29070019891 | Flange assembly | |
| 4 | 4030000048 | FRAME OIL SEAL | |
| 5 | 4030000768 | Sealing ring | |
| 6 | 4011001318 | Screw | |
| 7 | 29090007961 | WASHER | |
| 8 | 29070019901 | Sealing cover | |
| 9 | 4021000028 | BEARING | |
| 10 | 29070019911 | Bearing bushing | |
| 11 | 4021000139 | Roller bearing | |
| 12 | 29070019922 | Centre housing | |
| 13 | 4021000105 | Ball bearing | |
| 14 | 29070019932 | Differential housing | |
| 15 | 29070019941 | Adjusting nut | |
| 16 | 4011000597 | BOLT | |
| 17 | 29050015481 | Washer | |
| 18 | 3050900024 | STAY | |
| 19 | 4011000345 | Bolt | |
| 20 | 29070023881 | Crown wheel | |
| 21 | 29070019961 | Sleeve | |
| 22 | 29070019971 | Spacer sleeve | |
| 23 | 29070019981 | Spacer sleeve | |
| 24 | 29070019991 | Spacer sleeve | |
| 25 | 29070020001 | Spacer sleeve | |
| 26 | 29070020011 | Spacer sleeve | |
| 27 | 29070020021 | Spacer sleeve | |
| 28 | 29070020031 | Spacer sleeve | |
| 29 | 29070020041 | Spacer sleeve | |
| 30 | 3050900011 | ADJUST SHIM | |
| 31 | 29070010611 | Shim | |
| 32 | 29070010621 | Shim | |
| 33 | 29070010631 | Shim | |
| 34 | 3050900172 | SHIM | |
| 35 | 4011001281 | Screw | |
| 36 | 29070015981 | Washer | |
| 37 | 29070020082 | Centre housing | |
| 38 | 29070020091 | Bearing seat | |
| 39 | 29070019751 | Washer 1 | |
| 40 | 4011000951 | Screw | |
| 41 | 29070020102 | Differential housing | |
| 42 | 29070020611 | Shaft | |
| 43 | 29070020141 | Differential pinion | |
| 44 | 29070020151 | Thrust washer | |
| 45 | 29070020161 | Differential side gear | |
| 46 | 29070020171 | Thrust washer | |
| 47 | 29070000461 | PIN | |
| 48 | 4011000964 | Screw | |
| 49 | 29090007961 | WASHER | |
| 50 | 29070020601 | Differential housing | |
| 51 | 29070020122 | Differential housing | |
| 52 | 29070023891 | Crown wheel | |
| 53 | 29070023901 | Crown wheel | |
| 54 | 29070020052 | Connecting flange | |
| 55 | 3050900058 | Sealing ring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
