Каталог запасных частей к технике: SDLG LG918. SIGN AND LOGO
1
2
3
4
5
6
6
7
7
8
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 29360009511 | LUBRICATION DIAGRAM | |
| 2 | 29360008741 | ARM POSITION TO ENHANCE SAFETY SIGNS | |
| 3 | 29360009151 | NO PERSON LOGO | |
| 4 | 29360009231 | SIGNS TO AVOID ROLLING | |
| 5 | 4044000073 | MARK | |
| 6 | 29360008781 | GRAPHIC SIGNS ARTICULATED STEERING | |
| 7 | 29360010631 | 35 ANTIFREEZE LOGO | |
| 8 | 29360010641 | 45 ANTIFREEZE LOGO | |
| 9 | 4044000071 | SIGNAGE | |
| 10 | 29360009171 | HYDRAULIC TANK LOGO | |
| 11 | 29360009181 | HIGH TEMPERATURE WARNING SIGNS | |
| 12 | 26360000121 | SAFETY LOGO | |
| 13 | 29360007852 | STEAP TREAD | |
| 14 | 4044000018 | MARK-SLINGING | |
| 15 | 29360009191 | SIGNS BAN ON OPEN FIRES | |
| 16 | 29360012041 | MARKING OF LG918 | |
| 17 | 4044000054 | MARK-OIL TANK LGB401-F03/E | |
| 18 | 29360011841 | SGLG-350 | |
| 19 | 4044000052 | WARNING SIGNS | |
| 20 | 29360009211 | WARNING SIGNS ROTARY MACHINES | |
| 21 | 29360009221 | ACCSEE TO THE MACHINE MARKS | |
| 22 | 29360012061 | SDLG-500 | |
| 23 | 29360009161 | NOTE BENCH MARK | |
| 24 | 29360009531 | ATTENTION TO THE CAB DOOR SIGNS | |
| 25 | 29360012081 | SDLG-270 | |
| 26 | 29360009541 | DANGEROUS VOTAGE SIGNS | |
| 27 | 29360009251 | SEAT BELT WARNING SIGNS | |
| 28 | 29360009261 | SIGNS TO AVOID NOISE | |
| 29 | 29360009281 | INDIVIDUAL DRIVING SIGNS | |
| 30 | 29360009291 | CHECK MARK | |
| 31 | 29360011981 | MARKING | |
| 32 | 29360011980011 | SAFETY LOGO PACKAGE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
