Каталог запасных частей к технике: SDLG LG918. DIESEL ENGINE ASSEMBLY
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 3 | 4011000081 | BOLT | |
| 4 | 4110000560 | DIESEL ENGINE ASSEMBLY YC4D80-T10(D7019) | |
| 5 | 29010001071 | BOLT SHAFT | |
| 6 | 4014000020 | SCREW | |
| 7 | 4016000120 | SPLINT PIN | |
| 8 | 4013000028 | NUT | |
| 9 | 29010009202 | CABLE SHAFT | |
| 10 | 4120000119 | RUBBER TUBE | |
| 11 | 4030000288 | HOSE JB8406-B16x2000 | |
| 12 | 4120000067 | VALVE-HEATER | |
| 13 | 4017000024 | CLAMP | |
| 14 | 29010006671 | SHAFT | |
| 15 | 4120000096 | ACCELERATOR PEDAL | |
| 16 | 4015000035 | WASHER | |
| 17 | 4011000101 | BOLT | |
| 18 | 4011000488 | BOLT | |
| 19 | 29010006541 | HOLDER FOR AIR DRYER | |
| 20 | 4120000084 | AIR DYER | |
| 21 | 4120000750 | METAL TUBE | |
| 22 | 29220000171 | WASHER | |
| 23 | 29220001191 | CONNECTOR | |
| 24 | 29010006681 | JOINT FORK | |
| 25 | 4016000138 | PIN | |
| 26 | 4016000100 | SPLINT PIN | |
| 27 | 4041001224 | HOSE LGB144-105180 | |
| 28 | 29010006591 | DOUBLE BOLT | |
| 29 | 4013000011 | NUT | |
| 30 | 4015000168 | WASHER | |
| 31 | 4015000026 | WASHER | |
| 32 | 29010012051 | RUBBER SPACER | |
| 33 | 4011000656 | BOLT GB5782-M16x100EpZn-8.8 | |
| 34 | 4013000129 | NUT GB6170-M16EpZn-8 | |
| 35 | 4015000181 | WASHER | |
| 36 | 4011000641 | BOLT | |
| 37 | 4015000231 | WASHER | |
| 38 | 29010012001 | RUBBER SPACER | |
| 39 | 29010006601 | WASHER | |
| 40 | 4013000033 | NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
