Каталог запасных частей к технике: SDLG LG918. CAB
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
37
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4190000575 | BACK UP GLASS GROUP | |
| 2 | 4011000105 | BOLT | |
| 3 | 4015000036 | WASHER | |
| 4 | 4015000072 | WASHER | |
| 5 | 4190000586 | WOEKING LAMP | |
| 6 | 4190001614 | CAB GROUP | |
| 7 | 4190001005 | FRONT GLASS | |
| 8 | 4190001006 | FRONT GLASS SEAL | |
| 9 | 4190001007 | FRONT SIDE GLASS | |
| 10 | 4190000595 | COUNTER LOCK | |
| 11 | 4190001629 | RIGHT DOOR ASSEMBLY | |
| 12 | 4190000733 | DOOR GLASS | |
| 13 | 4190000734 | DOOR GLASS SEAL | |
| 14 | 4190000578 | DOME LAMP | |
| 15 | 4190000608 | ELECTRIC FAN | |
| 16 | 4014000063 | SCREW | |
| 17 | 4015000207 | WASHER | |
| 18 | 4015000035 | WASHER | |
| 19 | 4190000735 | REAR GLASS | |
| 20 | 4190000736 | REAR GLASS SEAL | |
| 21 | 4014000028 | SCREW | |
| 22 | 4190000737 | LEFT DOOR ASSEMBLY | |
| 23 | 4030000535 | OIL CUP | |
| 24 | 4190000739 | REAR SIDE GLASS SEAL | |
| 25 | 4190000738 | REAR SIDE GLASS | |
| 26 | 4190000587 | HAT | |
| 27 | 4190000588 | NUT | |
| 28 | 4190000589 | ROUND PAD | |
| 29 | 4015000256 | WASHER | |
| 30 | 4190000742 | RUBBER | |
| 31 | 4190000605 | LEFT LOCK | |
| 32 | 4190001758 | RIGHT LOCK | |
| 33 | 4190000596 | CHECK OF UPPER GATE | |
| 34 | 4190001613 | CAB WIRING | |
| 35 | 4190001009 | TRIM GROUP LG918 | |
| 36 | 29260000321 | WIRE | |
| 37 | 4190000652 | WIPER BUTTON ASSEMBLY LG952 | |
| 38 | 4190000600 | HAT | |
| 39 | 4190000767 | WIPER BUTTON PLATE LG952 | |
| 40 | 4011000289 | BOLT GB5783-M6x16EpZn-8.8 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
