1
2
3
4
5
6
7
8
9
10
11
11
12
12
13
13
13
14
15
Позиция на иллюстрации
Заводской номер детали
Название детали
1
11214725
Cable wiring harness
2
11214726
Cable wiring harness
3
11211358
Cable wiring harness
4
11214604
Support
5
11210476
Extractor
6
11214603
Support
7
11210257
Clip
8
11210255
Clip
9
11210259
Clip
10
11210260
Clip
11
11210619
Clip
12
11210033
Flange Bolt
13
11210034
Flange Bolt
14
11210036
Flange Bolt
15
11210042
Flange Bolt
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
