Каталог запасных частей к технике: SDLG LG6150E. 11212924 Hydraulic pump
11212821
1
1
2
3
4
4
5
6
7
8
8
9
9
10
10
10
10
11
11
12
12
13
13
14
15
15
16
16
17
18
18
19
20
20
21
22
23
24
25
25
26
26
27
27
28
28
29
29
30
31
31
32
32
33
34
35
36
36
37
38
38
39
39
40
40
40
41
41
42
42
43
43
43
43
44
45
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 11212821 | 11212821 | Pump | |
| 1 | 11213093 | Piston | |
| 2 | 11213091 | Cylinder | |
| 3 | 11213092 | Cylinder | |
| 4 | 11213098 | Plate | |
| 5 | 11213094 | Shaft | |
| 6 | 11213096 | Shaft | |
| 7 | 11213097 | Splined Sleeve | |
| 8 | 11213095 | Roller bearing | |
| 9 | 11213099 | Needle bearing | |
| 10 | 11213102 | Spacer | |
| 11 | 11213100 | Bushing | |
| 12 | 11213103 | Bushing | |
| 13 | 11213101 | Spring | |
| 14 | 11213112 | Bolt | |
| 15 | 11213113 | Plate | |
| 16 | 11213117 | Support | |
| 17 | 11213109 | Cover | |
| 18 | 11213107 | Case | |
| 19 | 11213108 | Body | |
| 20 | 11213110 | Bolt | |
| 21 | 11213110 | Bolt | |
| 22 | 11211697 | Plug | |
| 23 | 11213116 | Plug | |
| 24 | 11211417 | Plug | |
| 25 | 11213114 | Pin | |
| 26 | 11213104 | Piston | |
| 27 | 11213105 | Stop | |
| 28 | 11213111 | Stop | |
| 29 | 11213106 | O-ring | |
| 30 | 11213126 | O-ring | |
| 31 | 11213125 | O-ring | |
| 32 | 11213124 | O-ring | |
| 33 | 11210704 | O-Ring | |
| 34 | 11213123 | O-ring | |
| 35 | 11213122 | O-ring | |
| 36 | 11213121 | O-ring | |
| 37 | 11213120 | Sealing | |
| 38 | 11211068 | Ring | |
| 39 | 11213129 | Ring | |
| 40 | 11211544 | Nut | |
| 41 | 11211771 | Sealing ring | |
| 42 | 11213128 | Pin | |
| 43 | 11211415 | Spring pin | |
| 44 | 11211541 | Screw eye | |
| 45 | 11211559 | Screw | |
| 100 | 11213127 | Sealing Kit |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
