Каталог запасных частей к технике: SDLG L958F. Hydraulic control
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
10
11
11
12
12
13
14
15
16
16
17
17
18
19
19
20
20
21
21
21
21
22
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
39
40
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4011001510 | Screw | |
| 2 | 4041000011 | FLANGE | |
| 3 | 4030000130 | O-RING | |
| 4 | 4011001300 | Screw | |
| 5 | 4041000056 | FLANGE | |
| 6 | 4030000029 | O-RING | |
| 7 | 4041001957 | Hose assembly | |
| 8 | 29120023671 | Hose assembly | |
| 9 | 29120025131 | Bracket | |
| 10 | 4011001248 | Screw | |
| 11 | 4015000426 | Washer | |
| 12 | 4041002626 | Hose clamp | |
| 13 | 29120019531 | Plate | |
| 14 | 4011001568 | Screw | |
| 15 | 4013000370 | Nut | |
| 16 | 4015000433 | Washer | |
| 17 | 4011001238 | Screw | |
| 18 | 29120019621 | Bracket | |
| 19 | 4013000373 | Nut | |
| 20 | 29120016351 | MOUNTED PLATE | |
| 21 | 29120021551 | Clamp | |
| 22 | 4011001303 | Screw | |
| 23 | 26310002061 | Tarpaulin cover | |
| 24 | 4041002774 | Nipple | |
| 25 | 4041000768 | O-RING LGB168-11524 | |
| 26 | 4030000490 | O-RING | |
| 27 | 4041001063 | CONNECTOR LGB143-01810 | |
| 28 | 4041002505 | Hose assembly | |
| 29 | 4041000767 | O-RING | |
| 30 | 4041002773 | Nipple | |
| 31 | 4041001023 | JOINT | |
| 32 | 4030000240 | O-RING | |
| 33 | 29120020071 | Plate | |
| 34 | 4190000056 | Cable tie | |
| 35 | 4190001832 | Cable tie | |
| 36 | 4041001362 | Hose assembly | |
| 37 | 4041001554 | Hose assembly | |
| 38 | 4041002512 | Hose assembly | |
| 39 | 4041002513 | Hose assembly | |
| 40 | 4041001858 | Hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
