Каталог запасных частей к технике: SDLG L958F. Fan motor hydraulic system
1
2
3
4
5
5
6
7
7
8
9
10
11
12
12
12
12
12
12
13
14
14
15
16
17
18
18
18
19
20
21
22
23
24
25
26
27
27
28
28
29
30
31
32
33
34
35
35
36
37
38
38
38
38
38
39
40
41
42
43
43
44
44
45
46
47
48
49
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4041000043 | FLANGE | |
| 2 | 4011001300 | Screw | |
| 3 | 4030000026 | O-RING | |
| 4 | 29030023101 | Nipple | |
| 5 | 4041001718 | Tube lgb127-010090 | |
| 6 | 29030043811 | Pipe | |
| 7 | 4011001296 | Screw | |
| 8 | 4041001950 | Hose assembly | |
| 9 | 26150002251 | Clamp | |
| 10 | 4041000124 | Hose | |
| 11 | 4041001215 | Nipple | |
| 12 | 4041000779 | O-RING | |
| 13 | 4041001396 | Clamp | |
| 14 | 4013000370 | Nut | |
| 15 | 4011001381 | Bolt | |
| 16 | 4011001294 | Screw | |
| 17 | 29030043751 | Plate | |
| 18 | 4030000130 | O-RING | |
| 19 | 29030043761 | Pipe | |
| 20 | 4011000337 | BOLT | |
| 21 | 4011000478 | BOLT | |
| 22 | 4041002413 | Clamp | |
| 23 | 4011001297 | Screw | |
| 24 | 29030043741 | Hose assembly | |
| 25 | 4041001486 | Nipple | |
| 26 | 4030000211 | O-RING GB3452.1-30.0-2.65G | |
| 27 | 4120004698 | Nipple | |
| 28 | 4041001006 | CONNECTOR | |
| 29 | 29030042851 | Nipple | |
| 30 | 4120003299 | O-ring | |
| 31 | 29030039381 | Hose assembly | |
| 32 | 4041002328 | Hose assembly | |
| 33 | 4041003258 | Hose assembly | |
| 34 | 4041003090 | Hose assembly | |
| 35 | 4011001299 | Screw | |
| 36 | 29030022731 | Plate | |
| 37 | 4014000526 | Screw | |
| 38 | 4041000796 | CONNECTOR LGB120-02628 | |
| 39 | 4041000577 | STAIGHT JOINT LGB120-03633 | |
| 40 | 4041001446 | O-ring | |
| 41 | 4120005302 | Valve | |
| 42 | 29030042861 | Plate | |
| 43 | 29030022741 | Block | |
| 44 | 4011001274 | Screw | |
| 45 | 4120004418 | Oil filter | |
| 46 | 29030042871 | Plate | |
| 47 | 29030042881 | Clamp | |
| 48 | 4043003077 | Plate | |
| 49 | 4011001602 | Screw | |
| 50 | 4015000433 | Washer | |
| 51 | 4120004418001 | Filter insert |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
