Каталог запасных частей к технике: SDLG L953N. Hydraulic pump
1
2
3
4
5
6
7
8
9
10
10
11
11
12
12
13
13
13
14
14
15
16
17
17
17
18
19
20
21
22
23
24
25
25
26
26
27
27
28
28
28
28
29
29
29
30
30
30
31
32
33
34
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4120001715201 | Cover | |
| 2 | 4120006320001 | Centering block | |
| 3 | 4120006320002 | Pump body | |
| 4 | 4120006320003 | Drive shaft | |
| 5 | 4120001715205 | Shaft | |
| 6 | 4120006320004 | Shaft | |
| 7 | 4120006320005 | Side board | |
| 8 | 4120005082210 | Retaining ring | |
| 9 | 4120005082211 | Beaing | |
| 10 | 4120001715207 | Sealing ring | |
| 11 | 4120001058204 | Sealing ring | |
| 12 | 4120001715208 | O-ring | |
| 13 | 4120001715209 | Sealing ring | |
| 14 | 4120001715210 | Needle bearing | |
| 15 | 4120005082214 | Screw | |
| 16 | 4120001715211 | Pin | |
| 17 | 4120001715212 | Sealing ring | |
| 18 | 4120006320006 | Stud | |
| 19 | 4120004423216 | Nut | |
| 20 | 4120006320007 | Washer | |
| 21 | 4120006320008 | Cover | |
| 22 | 4120004423219 | Pump body | |
| 23 | 4120004423220 | Drive shaft | |
| 24 | 4120004423221 | Shaft | |
| 25 | 4120005081210 | Side board | |
| 26 | 4120005081211 | Plain bearing | |
| 27 | 4120005081212 | Pin | |
| 28 | 4120005081213 | Sealing ring | |
| 29 | 4120005081214 | Sealing ring | |
| 30 | 4120005081215 | Retaining ring | |
| 31 | 4120004423222 | Screw | |
| 32 | 4120006320009 | Washer | |
| 33 | 4120001084205 | Valve | |
| 34 | 4120006320010 | Sealing ring kit |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
