Каталог запасных частей к технике: SDLG L953N. Engine hood system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
33
34
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4190002281 | Door lock | |
| 2 | 4011000099 | Screw | |
| 3 | 4015000205 | Washer | |
| 4 | 4190002434 | Catch | |
| 5 | 4190002284 | Washer | |
| 6 | 29330022651 | EMPTY | |
| 7 | 29330035341 | Sponge | |
| 8 | 29330034262 | Bonnet | |
| 9 | 4011000560 | BOLT | |
| 10 | 29330035301 | Sponge | |
| 11 | 29330035511 | Sponge | |
| 12 | 29330035311 | Sponge | |
| 13 | 29330035321 | Sponge | |
| 14 | 29330056341 | Plate | |
| 15 | 29330056351 | Plate | |
| 16 | 4130000075 | BOLT GB16674-M6x12EpZn-8.8 | |
| 17 | 4011000197 | BOLT | |
| 18 | 4015000186 | WASHER | |
| 19 | 29330011232 | RUBBER COVER | |
| 20 | 29330018112 | Bonnet support | |
| 21 | 29330033881 | Sponge | |
| 22 | 29330033821 | Sponge | |
| 23 | 29330018121 | Cover | |
| 24 | 29330018131 | Cover | |
| 25 | 29330016921 | Hand rail | |
| 26 | 29330018141 | Bonnet support | |
| 27 | 29330033891 | Sponge | |
| 28 | 29330016941 | Bonnet | |
| 29 | 29330000081 | PNEUMATIC SPRING | |
| 30 | 29330033871 | Sponge | |
| 31 | 29330000092 | FRONT LOCK PLATE | |
| 32 | 29330001511 | PAD BLOCK | |
| 33 | 29330001531 | HINGE | |
| 34 | 4013000007 | NUT | |
| 35 | 29330016951 | Cover plate | |
| 36 | 29330016961 | Cover plate | |
| 37 | 29330016971 | Plate | |
| 38 | 29330016981 | Plate | |
| 39 | 29330033851 | Sponge | |
| 40 | 29330033841 | Sponge | |
| 41 | 29330016991 | Hand rail | |
| 42 | 29330033831 | Sponge | |
| 43 | 4030000535 | OIL CUP | |
| 44 | 29330017001 | Pull rod | |
| 45 | 29330017011 | Pull rod | |
| 46 | 4011000081 | BOLT | |
| 47 | 4015000197 | WASHER | |
| 48 | 4011000447 | BOLT | |
| 49 | 29330000171 | SHORT LINK | |
| 50 | 29330000181 | SHORT LINK | |
| 51 | 4011000477 | BOLT | |
| 52 | 29330001541 | RUBBER PAD | |
| 53 | 29330032051 | Cover plate | |
| 54 | 4013000011 | NUT | |
| 55 | 4011000479 | BOLT | |
| 56 | 29330043121 | Sponge | |
| 57 | 29330000201 | RUBBER COVER | |
| 58 | 29330020191 | Spacer | |
| 59 | 29330020201 | Spacer | |
| 60 | 29330001891 | HANDRAIL | |
| 61 | 4015000168 | WASHER | |
| 62 | 4016000035 | SPLIT PIN | |
| 63 | 29340009091 | LINK ASSEM | |
| 64 | 4011000594 | Screw | |
| 65 | 29330028191 | Attaching sleeve | |
| 66 | 29330020211 | SPACER | |
| 67 | 29330020221 | SPACER | |
| 68 | 29330034302 | Window | |
| 69 | 29330000241 | TURN PLATE | |
| 70 | 4016000114 | PIN | |
| 71 | 4016000119 | PIN | |
| 72 | 4015000162 | Washer | |
| 73 | 4015000207 | WASHER | |
| 74 | 4090000108 | Sealing strip | |
| 75 | 4090000107 | Sealing strip | |
| 76 | 4190000022 | Lock |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
