Каталог запасных частей к технике: SDLG L938F. Steering pump assembly
1
2
3
4
5
6
6
7
8
9
10
10
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
23
24
25
26
26
27
27
27
28
28
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4120005082201 | Cover | |
| 2 | 4120005081201 | Pump body | |
| 3 | 4120005081202 | Drive shaft | |
| 4 | 4120005081203 | Shaft | |
| 5 | 4120005081204 | Shaft | |
| 6 | 4120005082209 | Side board | |
| 7 | 4120005082210 | Retaining ring | |
| 8 | 4120005082211 | Beaing | |
| 9 | 4120005082212 | Sealing ring | |
| 10 | 4120005082213 | Plain bearing | |
| 11 | 4120005082214 | Screw | |
| 12 | 4120005082215 | Pin | |
| 13 | 4120005082216 | O-ring | |
| 14 | 4120005082217 | Sealing ring | |
| 15 | 4120005082218 | Retaining ring | |
| 16 | 4120005081205 | Stud | |
| 17 | 4120005082220 | Nut | |
| 18 | 4120005082221 | Washer | |
| 19 | 4120005081206 | Cover | |
| 20 | 4120005081207 | Pump body | |
| 21 | 4120005081208 | Drive shaft | |
| 22 | 4120005081209 | Shaft | |
| 23 | 4120005081210 | Side board | |
| 24 | 4120005081211 | Plain bearing | |
| 25 | 4120005081212 | Pin | |
| 26 | 4120005081213 | Sealing ring | |
| 27 | 4120005081214 | Sealing ring | |
| 28 | 4120005081215 | Retaining ring | |
| 29 | 4120005081216 | Screw | |
| 30 | 4120005081217 | Washer | |
| 31 | 4120005081218 | Sealing ring kit |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
