Каталог запасных частей к технике: SDLG G9190. Transmission assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
23
24
25
26
27
28
29
30
31
32
33
33
34
34
35
35
36
37
38
38
39
40
41
42
43
44
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4110001905 | Gearbox | |
| 2 | 4120000145 | Nipple | |
| 3 | 28060003111 | Tube | |
| 4 | 4011000378 | Bolt | |
| 5 | 29050019331 | Washer | |
| 6 | 4110001527 | Absorber | |
| 7 | 28060002951 | Gearbox mounting | |
| 8 | 4015000176 | WASHER | |
| 9 | 4011000168 | BOLT GB5783-M20x40EpZn-8.8 | |
| 10 | 28060003861 | Washer | |
| 11 | 4013000157 | NUT | |
| 12 | 28060002991 | Gearbox mounting | |
| 13 | 28060003151 | Radiator | |
| 14 | 4120003593 | Nipple | |
| 15 | 28060003161 | Hose | |
| 16 | 4011000106 | BOLT | |
| 17 | 4015000072 | WASHER | |
| 18 | 28060003041 | Flange | |
| 19 | 4017000008 | CLAMP | |
| 20 | 28060003211 | Guide tube | |
| 21 | 28060003611 | Mudguard | |
| 22 | 4011000089 | BOLT | |
| 23 | 28120002011 | Washer | |
| 24 | 4041000508 | THREAD PLUG | |
| 25 | 4041000768 | O-RING LGB168-11524 | |
| 26 | 4011000080 | BOLT | |
| 27 | 4015000197 | WASHER | |
| 28 | 4110002030 | Dipstick | |
| 29 | 4015000256 | WASHER | |
| 30 | 4011000105 | BOLT | |
| 31 | 28060003071 | Inlet pipe | |
| 32 | 4120004007 | Oil filter | |
| 33 | 4017000010 | CLIP JB8870-d20 | |
| 34 | 4015000140 | WASHER JB982-10 | |
| 35 | 28060003361 | Nipple | |
| 36 | 4030000558 | Hose | |
| 37 | 28060003501 | Seat | |
| 38 | 4015000162 | Washer | |
| 39 | 4011000082 | BOLT | |
| 40 | 4015000110 | WASHER | |
| 41 | 4014000023 | SCREW | |
| 42 | 28060003491 | Protecting cover | |
| 43 | 4120005062 | Breather cap | |
| 44 | 4030000974 | Hose | |
| 45 | 4011000084 | BOLT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
