Каталог запасных частей к технике: SDLG G9190. Engine hood

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Позиция на иллюстрации Заводской номер детали Название детали
1 28280007051 Plate
2 28280007381 Plate
3 28280007591 Cover plate
4 4011000087 BOLT
5 28280007801 Cover plate
6 28280007901 Guide member
7 4013000007 NUT
8 4011000081 BOLT
9 4190002899 Air spring
10 28280006621 Sponge
11 4011000091 BOLT
12 28280006431 Sponge
13 28280006631 Sponge
14 28280005901 Framework
15 28280006461 Sponge
16 29330011232 RUBBER COVER
17 4015000186 WASHER
18 28280006531 Sponge
19 28280006591 Sponge
20 4011000101 BOLT
21 28280005681 Cover
22 28280006541 Sponge
23 28280006551 Sponge
24 28280006601 Sponge
25 28280006651 Sponge
26 28280006511 Sponge
27 28280006491 Sponge
28 28280006521 Sponge
29 29330016461 RIGHT UPPER HANDRAIL
30 29330016441 LEFT UPPER HANDRAIL
31 28280006731 Grille
32 29330022651 EMPTY
33 28280006711 Cover
34 28280006581 Sponge
35 28280005831 Gate
36 28280006151 Iron net
37 29330000092 FRONT LOCK PLATE
38 29330000171 SHORT LINK
39 4015000162 Washer
40 4016000119 PIN
41 29330000241 TURN PLATE
42 4015000207 WASHER
43 4016000114 PIN
44 28280005771 Sponge
45 28280006421 Attaching member
46 28280006471 Sponge
47 29330028191 Attaching sleeve
48 4011000150 BOLT
49 28280006391 Housing
50 4011000197 BOLT
51 4011000082 BOLT
52 4015000197 WASHER
53 29330000201 RUBBER COVER
54 28280006741 Plate
55 28280007581 Cover plate
56 4190000916 LOCK
57 4011000089 BOLT
58 4030000535 OIL CUP
59 28280005161 Gate
60 28280005201 Gate
61 29330028501 Sealing strip
62 4030000749 Sealing strip
63 4190002768 Rubber moulding
64 4190002284 Washer
65 4011000423 Screw
66 4190002283 Catch
67 4015000205 Washer
68 4011000099 Screw
69 4190002281 Door lock
70 28280006501 Sponge
71 28280006561 Sponge
72 28280006641 Sponge
73 28280006661 Sponge
74 28280007331 Sponge
75 28280007311 Sponge
76 28280007271 Sponge
77 28280006571 Sponge
78 28280007301 Sponge
79 28280007281 Sponge
80 28280006441 Sponge
81 28280006451 Sponge
82 29360015191 Emblem
83 28280006411 Attaching member
84 28280006481 Sponge
85 28280007291 Sponge
86 29330000181 SHORT LINK
87 28280006611 Sponge
88 28280005821 Gate
89 28280008171 Sponge
90 29330041891 Hand rail
91 29340009091 LINK ASSEM
92 4016000035 SPLIT PIN
93 28280007321 Sponge
94 29330041871 Hand rail
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
