Каталог запасных частей к технике: SDLG G9190. Electric system
1
1
2
2
3
4
5
6
7
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
20
21
22
22
22
23
24
25
26
31
31
31
33
35
36
37
38
39
39
40
41
42
43
44
45
46
47
48
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4130001314 | Tail lamp | |
| 2 | 4130001685 | Lamp | |
| 3 | 28320003842 | Cable harness | |
| 4 | 4190000020 | CLIP | |
| 5 | 26370002451 | Cable sleeve | |
| 6 | 29370014401 | Battery cable | |
| 7 | 4011000447 | BOLT | |
| 8 | 29370021771 | Battery cable | |
| 9 | 4130001422 | Switch | |
| 10 | 26370002441 | Cable sleeve | |
| 11 | 28320004111 | Battery cable | |
| 12 | 29370016701 | Cable sleeve | |
| 13 | 4130000045 | BATTERY 6-QW-70 | |
| 14 | 29370014261 | BATTERY WIRE P50x150 | |
| 15 | 29370016691 | Cable sleeve | |
| 16 | 4130000994 | Preheater relay | |
| 17 | 4130000075 | BOLT GB16674-M6x12EpZn-8.8 | |
| 18 | 4013000028 | NUT | |
| 19 | 28320004211 | Battery cable | |
| 20 | 11214361 | Strip clamp | |
| 21 | 4130002002 | Position switch | |
| 22 | 4011000153 | BOLT | |
| 23 | 4130001286 | Horn | |
| 24 | 4130001047 | Lamp | |
| 25 | 4130001048 | Lamp | |
| 26 | 4130001287 | Horn | |
| 27 | 26370001941 | Clamp | |
| 28 | 4190001839 | Cable tie | |
| 29 | 28320004101 | Battery cable | |
| 30 | 4130001296 | Pressure switch | |
| 31 | 4011000458 | BOLT | |
| 32 | 26370001072 | Bracket | |
| 33 | 4130001722 | Temperature sensor | |
| 34 | 4011000807 | Bolt | |
| 35 | 4130002050 | Pressure switch | |
| 36 | 4130001956 | Tachometer sensor | |
| 37 | 28320003831 | Cable harness | |
| 38 | 4130001897 | Rocker switch | |
| 39 | 4130000572 | Независимый одинарный каркас | |
| 40 | 4130001955 | Rocker switch | |
| 41 | 4130001954 | Rocker switch | |
| 42 | 4130001895 | Rocker switch | |
| 43 | 4130001894 | Rocker switch | |
| 44 | 4130001087 | Switch | |
| 45 | 28320003811 | Cable harness | |
| 46 | 28320003822 | Cable harness | |
| 47 | 4130001899 | Fuse and relay unit | |
| 48 | 4015000207 | WASHER | |
| 49 | 4014000042 | Screw | |
| 50 | 4013000118 | NUT GB6170-M5EpZn-8 | |
| 51 | 4015000110 | WASHER | |
| 52 | 29370024041 | Plate | |
| 53 | 28320003851 | Cable harness | |
| 54 | 4130000869 | Relay | |
| 55 | 4130001086 | Engine control module | |
| 56 | 4130001900 | Cable harness | |
| 57 | 4014000174 | Screw | |
| 58 | 28320004131 | Bracket | |
| 59 | 4014000267 | Screw | |
| 60 | 4015000200 | Washer | |
| 61 | 4013000159 | Nut | |
| 62 | 4130000912 | Relay | |
| 63 | 4014000088 | SCREW | |
| 64 | 4015000110 | WASHER | |
| 65 | 28320003871 | Display panel | |
| 66 | 4130001081 | Accelerator pedal | |
| 67 | 4130000121 | Buzzer | |
| 68 | 4130001898 | Fuel level sensor | |
| 69 | 4130001101 | Work lamp |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
