Каталог запасных частей к технике: SANY YZ20C. 10205474 Wire,connecting,panel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | A241900000523 | Wire, red | |
| 2 | A241900000524 | Wire, black | |
| 3 | A241400000161 | Tube, numbering | |
| 4 | A241900000526 | Wire, yellow | |
| 5 | B241000000064 | Sleeve GP, plug, 16-pin | |
| 6 | B241200000459 | Pin,contact | |
| 7 | B241200000461 | Plug, water | |
| 8 | A241300000019 | Fuse, plate type | |
| 9 | A241300000016 | Fuse, plate type | |
| 10 | A241300000018 | Fuse, plate type | |
| 11 | A241300000210 | Fuse, chip | |
| 12 | 60015734 | Fuse, chip | |
| 13 | A249900000526 | Box, fuse | |
| 14 | B241000000004 | Sleeve, protective, plug, three-wire | |
| 15 | B241000000002 | Plug, chip-type | |
| 16 | B241000000003 | Jacket, plug, two-wire | |
| 17 | B241000000019 | Sealing parts | |
| 18 | A241000000030 | Plug, chip | |
| 19 | A241000000050 | Sleeve GP, socket, 3-wire | |
| 20 | A241000000072 | Sleeve GP, plug, single-wire | |
| 21 | A241200000179 | Assembly, plug jacket, 2-line | |
| 22 | A242000000007 | Terminal UT 1-3 | |
| 23 | A242000000309 | Terminal | |
| 24 | A241000000040 | Socket, blade, DJ623-A6.3B | |
| 25 | A241900000531 | Wire |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
