Каталог запасных частей к технике: SANY YZ18C. 10654044 Hydraulic system GP
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B210780001171 | Nipple,pipe | |
| 2 | B210780000587 | Connector, pipe | |
| 3 | B210780000017 | Pipe joint EL15LOMDA3C | |
| 4 | B210770000083 | Pressure tap | |
| 5 | B210780000043 | End straight coupling | |
| 6 | B210780000041 | Connector, pipe | |
| 7 | A810201060007 | Mounting, joint, multi-way | |
| 8 | B210780001749 | Connector, pressure measuring, SKK20-M12x1.5-PC | |
| 9 | B210780000049 | Connector, hose, GE22LMEDOMDA3C | |
| 10 | B210780000025 | FITTING - PIPE | |
| 11 | B210399000005 | Screw plug, VSTI18x1.5EDA3C | |
| 12 | B220400000099 | Valve, check | |
| 13 | B210780001175 | Joint, pressure-measuring | |
| 14 | B210780000018 | FITTING - PIPE | |
| 15 | B210780000107 | Pipe joint GE22L11/16UNFOMDA3C | |
| 16 | B210780000683 | Connector, pipe | |
| 17 | B210780000004 | Flange, split | |
| 18 | B210299000026 | Screw, hexagon | |
| 19 | A210401000002 | Washer | |
| 20 | B230101000043 | O-ring | |
| 21 | B210780000186 | Connector, pipe | |
| 22 | B210780000793 | Connector, pipe | |
| 23 | B210780000898 | Nipple,pipe | |
| 24 | B210780000070 | Connector, pipe | |
| 25 | B210780000148 | Connector, pipe | |
| 26 | B210780000015 | Connector, hose, EL10LOMDA3C | |
| 27 | B210780000021 | Connector | |
| 28 | B210780000059 | Joint, flanged | |
| 29 | B210780000054 | Pipe joint GE35LMEDOMDA3C | |
| 30 | A810201060003 | Clamp AS, pipe | |
| 31 | B210780000036 | Connector, pipe | |
| 32 | B210780000636 | Connector, hose, EW10LOMDA3C | |
| 33 | 10653957 | Hose GP, hydraulic | |
| 34 | B210780000644 | Flange, split | |
| 35 | B230101000091 | O-RING | |
| 36 | A210204000163 | Screw | |
| 37 | A210401000001 | Washer | |
| 38 | B210780000838 | Connector, pipe | |
| 39 | B210780000030 | Connector, hose, EW35LOMDA3C | |
| 40 | B210780000040 | Connector, hose, GE15LMEDOMDA3C | |
| 41 | B210780001246 | Pipe joint RED15/12LOM3C | |
| 42 | B210780000007 | Flange, split | |
| 43 | B210299000005 | Screw, hexagon | |
| 44 | A210609000038 | O-ring | |
| 45 | B210780000074 | Connector, pipe |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
