Каталог запасных частей к технике: SANY SYM5190THBDZ 30. 13432022 Mounting, tank, oil
1
2
3
4
4
5
5
6
6
7
7
8
9
9
9
9
9
9
10
11
12
13
14
15
16
17
18
18
18
19
20
21
22
23
24
25
26
27
27
28
29
30
31
32
33
34
34
34
34
35
36
37
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 13432028 | Hydraulic oil tank | |
| 2 | 60101257 | Filter, oil suction | |
| 3 | 13432020 | Rod,connecting | |
| 4 | 12563841 | Cover, oil return | |
| 5 | A210111000202 | Bolt | |
| 6 | A210405000001 | Washer | |
| 7 | A210401000002 | Washer | |
| 8 | A210111000197 | Bolt | |
| 9 | A210401000001 | Washer | |
| 10 | A210405000011 | Washer | |
| 11 | 60193268 | Filter, Air, lock | |
| 12 | 13432032 | Seat,air cleaner | |
| 13 | A210609000294 | O-ring | |
| 14 | A210405000008 | Washer | |
| 15 | A210111000367 | Bolt | |
| 16 | A250100000041 | Gauge, liquid level and temperature | |
| 17 | 13026134 | Flange, oil return | |
| 18 | 23000066 | Screw | |
| 19 | 12820857 | Plate, cover, flange | |
| 20 | A820205001205 | Connector | |
| 21 | 24001173 | Plug, screw | |
| 22 | A220400000004 | Valve, ball | |
| 23 | 60193267 | Element GP, filter, return oil | |
| 24 | A210608000151 | O-ring | |
| 25 | 12953605 | Seat, oil suction | |
| 26 | B210399000002 | Screw plug, VSTI16x1.5EDA3C | |
| 27 | 21010435 | O-ring | |
| 28 | B210361000000 | Plug, Screw | |
| 29 | 13432021 | Plate, backup, rubber | |
| 30 | A210111000243 | Bolt | |
| 31 | A210401000004 | Washer | |
| 32 | A210405000003 | Washer | |
| 33 | 12562209 | Plate, cover, flange | |
| 34 | A210609000314 | O-ring | |
| 35 | A210204000354 | Screw | |
| 36 | 12666824 | Cover, protective | |
| 37 | A210401000017 | Washer | |
| 38 | A210204000146 | Screw, M8x16 GB70.1 | |
| 39 | 13026128 | Plate, cover, flange | |
| 40 | A210204000161 | Screw |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
