Каталог запасных частей к технике: SANY SYM5190THBDZ 30. 13234624 Hydraulic systemпјЊmixing system
1
2
3
4
6
6
14
15
16
17
18
19
20
21
22
23
23
23
24
25
26
32
33
33
42
42
43
44
45
45
46
48
49
49
50
51
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B230103000393 | Hose, rubber | |
| 2 | B230103000396 | Hose, rubber, 2SN16-DKOL-DKOL90-750Q/SY1102 | |
| 3 | B230103003877 | Hose, rubber | |
| 4 | B210780000131 | Connector, hose, GE18LMEDOMDA3C | |
| 6 | B210780000157 | Connector, pipe | |
| 14 | B230103000475 | Hose, rubber | |
| 15 | 13022652 | Plate, fixed,oil pipe | |
| 16 | B210780000036 | Connector, pipe | |
| 17 | B230103003976 | Hose, rubber | |
| 18 | 60019596 | Hose, rubber | |
| 19 | A210111000088 | Bolt | |
| 20 | B210780001310 | Connector, hose, EW18LOMDA3C | |
| 21 | 13021768 | Pipe, steel | |
| 22 | 13020949 | Pipe, oil | |
| 23 | 60014675 | Body, pipe clamp | |
| 24 | 13022454 | Plate, set | |
| 25 | 12638346 | Plate, mounting | |
| 26 | B210780000245 | Connector, pipe | |
| 32 | A210204000147 | Screw | |
| 33 | A210405000007 | Washer | |
| 42 | B230103005263 | Hose, rubber | |
| 43 | 60025953 | Hose, rubber | |
| 44 | B230103004932 | Hose, rubber | |
| 45 | B230103007086 | Hose, rubber | |
| 46 | 60019593 | Hose, rubber | |
| 48 | 12923155 | Hose, rubber | |
| 49 | B230103003869 | Hose, rubber | |
| 50 | B210780001007 | Connector, pipe | |
| 51 | B230103003870 | Hose, rubber |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
