Каталог запасных частей к технике: SANY SY75C9I2H. 12158687 Pipeline, main, hydraulic
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
16
16
17
17
17
17
18
19
19
20
20
21
22
23
24
24
25
25
26
26
27
27
28
28
29
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 11664307 | Block, mounting | |
| 2 | A820202005473 | Clamp, pipe, rubber | |
| 3 | A210204000335 | Screw | |
| 4 | A210401000017 | Washer | |
| 5 | A820601040450 | Clip, hose | |
| 6 | A820101357603 | Plate, pressure | |
| 7 | A210204000357 | Screw | |
| 8 | 12158635 | Tank GP, hydraulic | |
| 9 | A210204000198 | Screw | |
| 10 | A210405000003 | Washer | |
| 11 | 10620906 | Connector | |
| 12 | B210780001397 | Choke plug | |
| 13 | 60015195 | Valve, main control | |
| 14 | A210204000356 | Screw | |
| 15 | A210204000215 | Screw | |
| 16 | 60028445 | Hose | |
| 17 | B230103005734 | Hose | |
| 18 | B230103001586 | Hose | |
| 19 | B230103005609 | Hose | |
| 20 | B230103006472 | Hose | |
| 21 | 10209832 | Clamp, pipe | |
| 22 | 24002398 | Screw M8x50GB70.1 12.9 | |
| 23 | A810201024807 | Pipe, oil return | |
| 24 | B210780000824 | Connector, pipe | |
| 25 | B210780000184 | Connector, hose, GE18LR3/4EDOMDA3C | |
| 26 | A820205002377 | Connector | |
| 27 | A230101000244 | O-ring | |
| 28 | A820205002378 | Connector | |
| 29 | A230101000243 | O-ring | |
| 30 | 12157657 | Sponge, hydraulic tank | |
| 31 | A210204000130 | Screw | |
| 32 | A210405000006 | Washer | |
| 33 | 60049793 | Valve, breather | |
| 34 | 12796771 | pipeline bearer | |
| 35 | A210111000024 | Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
