11818935 Drawing, assembly, electrical system
Каталог запасных частей к технике: SANY SY55C9. 11818935 Drawing, assembly, electrical system
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
Ammann
BOMAG
CARMIX
CASE IH
Changlin
ChengGong
Dimex
Doosan
DYNAPAC
Foton
HAMM
Hidromek
Hitachi
Hyundai
JCB
JLG
John Deere
Komatsu
LIEBHERR
LiuGong
Lonking (LongGong)
Luneng
MANITOU
Mitsuber
New Holland
PENGPU
RM-Terex
SANY
SDLG
SEM
Shantui
Shehwa HBXG
Soosan
TIGARBO
VOGELE
Volvo
WAY
WIRTGEN
XCMG
XGMA
Xiamen
YTO
Yuchai
Zoomlion
Автокран
АЗСМ
Алтайлесмаш
Амкодор
АОМЗ
Атек
АТЗ
Балканкар Рекорд
БелАЗ
Беловеж
Борекс
Брянский Арсенал
Булат
ВЭКС
ГАЗ
Геомаш
Гидромаш
Донекс
Дормаш
Дормашина
Дорэлектромаш
ДЭЗ
ЕлАЗ
ЗЗГТ
Ижнефтемаш
Канаш-электрокар
КЗКТ
ККЗ
Клевер
Клинцовский автокрановый завод
КМЗ
КМЗ 1 Мая
Ковровец
Коммаш
Кранэкс
КЭЗ
КЭМЗ
ЛЗА
МАЗ
МЗИК
МЗКМ
МЗКТ
Михневский РМЗ
МоАЗ
Мозырский МЗ
МТЗ
ОЗП
Онежец
ПАО "ТЗА"
ППС Детва
Промтрактор
ПТЗ
Раскат
СпецАгрегат
ТВЭКС
ТТМ
УВЗ
Угличмаш
УЗТМ
ХТЗ
ЧЗКМ
ЧСДМ
ЧТЗ
ЭКСКО
ЭКСМАШ
ЮрМаш
Модель
Не выбрано
QY50CS93
RSC45C
RSC45C
SDCY90K6C
SSR120AC-8
STC250H
STC250S5
STG190C-8
SY135C8
SY210C8
SY215C9
SY335C8
SY5250GJB6C
SY5320THB 470C-8S
SY55C9
SY65C
SY75C
SY75C9I2H
SYM5190THBDZ 30
YZ18C
YZ20C
Схема
>
Не выбрано
12081620 Hydraulic Excavator
12118680 Slewing device
12118680 Slewing device
12112475 Pipeline, pilot
12112475 Pipeline, pilot
12112475 Pipeline, pilot
11168808 Joystick AS, left
11168809 Joystick AS, right
B229900001009 Valve, pilot
B220400000388 Valve, oil source control
B229900000063 Filter, oil
12088849 Cab GP
60142949 Cab
60142949 Cab
60142949 Cab
60142949 Cab
60142949 Cab
60142949 Cab
60142949 Cab
60142949 Cab
60142949 Cab
60142949 Cab
60080856 Door AS, cab
60080859 Window, front
10587443 Control mechanism, travel
12826254 Seat and control cabinet SY60.1.5.3A
60197277 Mechanical Suspension Driver seat
10539594 Support, bottom plate
11147622 Cover GP
11147622 Cover GP
11147622 Cover GP
11147622 Cover GP
11147622 Cover GP
11315197 Bracket GP
11301628 Door GP, access
11328935 Cover AS
11328611 Door GP
11303099 Toolbox GP
11636615 Lock catch AS
11463118 Lock catch AS
12488758 Power system SY55C9I2R.1.3
11189427 Cooling system
60042304 Radiator
60045691 Engine
60029665 Cover, valve mechanism
60029664 Cylinder Head
60029666 Cylinder block
60029666 Cylinder block
60029673 Oil pan & engine oil level gauge
60029670 Camshaft & valve mechanism
60029667 Crankshaft & piston & flywheel
60029671 Timing gearbox and flywheel housing
60029660 Manifold, inlet
60029661 Manifold, exhaust
60029644 Breather
60029643 Fuel injection system
60029662 Lines, fuel injection pump
60029663 Connecting parts, fuel injection pump
60029646 Pump, fuel injection
60029654 Regulator, Speed
60029654 Regulator, Speed
60029647 Pump, fuel priming (manual)
60029652 Coupling, fuel injection pump
60029648 Pump, water
60029656 Pipe, water (engine)
60029659 Thermostat
60029672 Fan & belt
60029645 Pump, engine oil
60029658 Lines, engine oil
60029651 Starting motor
60029650 Alternator
60029668 Lines, fuel
60029655 Bracket, idler gear
60029657 Bracket
60029649 Filter, engine oil
60029669 Fuel filter & bracket
11189428 Air inlet system
60218893 Air cleaner
11189426 Exhaust system
11885791 Fuel system
13208036 Fuel Tank Assy SY60C1I2R.1.3.5.1A
60064763 Fuel coarse filter
12488634 Transmission and damping system SY55C9I2
10542509 Counterweight GP
12112468 Pipeline, main, hydraulic
12112468 Pipeline, main, hydraulic
12112468 Pipeline, main, hydraulic
12112468 Pipeline, main, hydraulic
60118959 Pump, plunger
B229900005731 Reducer GP
60164190 HYDRAULTC MOTOR GROUP
60164187 Relief Valve
60255065 REDUCTION GEAR ASSEMBLY
60167417 Valve, main control
60086730 Plate GP, oil inlet valve
60086713 Plate GP, valve, boom
60086710 Plate GP, valve, bucket
60086714 Plate GP, valve, arm
60086733 Plate GP, travel valve
60086726 Plate GP, valve, auxiliary
60086732 Plate GP, dozer blade valve
60086728 Plate GP, swing valve
13146880 Hydraulic Fuel Tank Assy. SY55C3I2R.1.2.
11142074 Plate AS, sealing
11178836 Air conditioning system
60041328 Air conditioning system
60171283 Evaporator Assy
10620902 Chamber AS, wind, air conditioner
11571667 Travel device
11571667 Travel device
11571667 Travel device
11571667 Travel device
11571667 Travel device
11044379 Track AS
A229900002163 Wheel, idler
60011764 Idler tensioner AS
11951609 Track Roller
11567524 Hydraulic system, undercarriage
11567524 Hydraulic system, undercarriage
11567524 Hydraulic system, undercarriage
11567524 Hydraulic system, undercarriage
11567524 Hydraulic system, undercarriage
A229900004501 Connector, central slewing
60166522 Reducer GP
60216967 Motor
60216967 Motor
60216967 Motor
60218534 Reducer
11309667 Bearing,slewing
12120044 Work equipment
12120044 Work equipment
12120044 Work equipment
12120044 Work equipment
12120044 Work equipment
12120044 Work equipment
12120044 Work equipment
12120044 Work equipment
12120044 Work equipment
10544885 Pipeline, work equipment
10544885 Pipeline, work equipment
60199322 Cylinder, arm
60199321 Cylinder, boom
60199320 Cylinder, bucket
12158004 Bucket SY55C9I2R.3.4
12158015 bucket body SY55C9I2R.3.4.1
11818935 Drawing, assembly, electrical system
11818935 Drawing, assembly, electrical system
12318633 Integrated box
11326577 Painting, excavator
11326577 Painting, excavator
11376772 Accessories
A810509000100 Tool, attached
A290000000155 Toolbox, portable
60225750 Pilot-control Valve
60004100 Valve, foot
60004100 Valve, foot
60004100 Valve, foot
11694458 Cylinder,push plate
Other Fittings
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Позиция на иллюстрации
Заводской номер детали
Название детали
1
12709411
Sany encourage control display
2
60053221
Lamp, indicator, LED, yellow
3
60117463
Switch, fuel control
4
12677339
Harness of arm-rest box
5
60053220
Lamp, indicator, LED, red
6
A241200001217
Switch, start
7
12694911
Fixed sheet
8
12677338
Driver's cab harness
9
60205002
Radio
10
12318633
Integrated box
11
60202078
Cluster fixed lace
12
A210210000030
Screw
13
A210404000010
Washer
14
11732666
Harness, control switch
15
A241300000059
Box, fuse
16
12364933
Relay mounting plate
17
12353689
Relay protective cover
18
A210111000079
Bolt
19
A210404000009
Washer
20
60064784
Wire, power supply
21
11400099
Clip
22
60161351
Workinglight
23
60023703
Horn
24
60023704
Antenna
