Каталог запасных частей к технике: SANY SY5320THB 470C-8S. 12831484 Hydraulic system, swing cylinder

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
10
16
23
23
39
46
52
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
80
Позиция на иллюстрации Заводской номер детали Название детали
2 B210780000319 Connector, pipe
10 B230103003914 Hose, rubber
16 B210780000052 Connector, pipe
23 B210780000636 Connector, hose, EW10LOMDA3C
39 B210780000053 Pipe joint GE30SMEDOMDA3C
46 60014672 Body, clamp
52 12707826 Connector, damping
54 A820205000005 Connector, pipe, U-shaped
55 B220400000101 Valve, one-way
56 B230103004202 Hose, rubber
57 12680301 Connector, pipe
58 12655100 Pipe, oil
59 A820205001687 Connector body, pipe, accumulator
60 B230101001046 O-ring
61 B230101000244 O-ring
62 A820606010001 Pad
63 B229900003708 Accumulator, EHV10-330/90
64 11781856 Flange, oil return, swing valve
65 B230101000647 O-ring
66 A210204000014 Screw
67 B250202000006 Gauge, pressure
68 60209245 Pipe, pressure measuring
69 A820205001244 Body, connector, oil, inlet and outlet, swing cylinder
70 B220400000213 Valve, one-way
71 A820205000206 Joint, articulated
72 B230103003869 Hose, rubber
73 A820205000812 Adaptor, accumulator, main valve block
74 B210780001394 Connector, pipe
75 B230103002706 Hose, rubber
76 12825364 Pipe, steel,
77 24001084 Flange, SAE
80 A210401000001 Washer
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
