Каталог запасных частей к технике: SANY SY5320THB 470C-8S. 12828050 Hydraulic system, mixing

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
5
5
8
8
8
9
27
32
33
34
35
36
36
36
37
38
39
40
41
42
43
44
45
45
46
47
48
49
50
51
53
54
55
56
57
58
59
60
61
62
63
Позиция на иллюстрации Заводской номер детали Название детали
5 B230103000396 Hose, rubber, 2SN16-DKOL-DKOL90-750Q/SY1102
8 B210780001310 Connector, hose, EW18LOMDA3C
9 B210780000157 Connector, pipe
27 B230103000390 Hose, rubber
32 B210780000232 Connector, hose, GE12LM14x1.5EDOMDA3C
33 B210780000024 Connector, hose, EW12LOMDA3C
34 B230103003857 Hose, rubber
35 12843267 Pipe, steel, oil drain, mixing system
36 60014675 Body, pipe clamp
37 B230103000394 Hose, rubber
38 A832613125000 Hose, rubber
39 12843250 Pipe, steel, oil drain, mixing system
40 12843370 Pipe, steel, oil return, auxiliary valve
41 B250202000005 Gauge, pressure
42 B230103007358 Pipe, pressure measuring
43 B230103000397 Hose, rubber
44 B230103003511 Hose, rubber
45 B210780001007 Connector, pipe
46 10909558 Pipe, steel, oil drain, mixing motor
47 A820205000198 Body, connector, oil, inlet and outlet, motor
48 A820205000197 Body, connector, oil, drain, motor
49 B210780001394 Connector, pipe
50 B210780000245 Connector, pipe
51 B230103001231 Hose, rubber
53 B230103003858 Hose, rubber
54 12819535 Pipe, steel, transition
55 B230103000382 Hose, rubber
56 12843332 Pipe, steel, oil inlet, auxiliary valve
57 B230103003976 Hose, rubber
58 B230103005263 Hose, rubber
59 B210780000636 Connector, hose, EW10LOMDA3C
60 B210780000036 Connector, pipe
61 B230103000478 Hose, rubber
62 B210780000683 Connector, pipe
63 B210780000019 Connector, pipe
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
