Каталог запасных частей к технике: SANY SY5320THB 470C-8S. 12828047 Pipeline, hydraulic, revolving tower

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
19
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
62
71
72
82
84
86
87
88
92
Позиция на иллюстрации Заводской номер детали Название детали
19 60014674 Body, pipe clamp
25 21024136 Hose
26 21050783 Connector, pipe
27 60212560 Hose, rubber
28 60019597 Hose, rubber
29 A210401000002 Washer
30 A210111000040 Bolt
31 B230103008158 Hose, rubber
32 60185722 Connector, filter
33 60212562 Hose, rubber
34 12824369 Pipe, oil
35 12824351 Pipe, oil
36 A239900000053 Tape, binding, nylon
37 60061016 Tape, binding, colored
38 60061017 Tape, binding, colored
39 60061018 Tape, binding, colored
40 60061019 Tape, binding, colored
41 60014677 Body, clamp
42 60216038 Rubber hose
43 60216035 Rubber hose
44 60216036 Rubber hose
45 60216040 Rubber hose
46 60216039 Rubber hose
47 11805684 Sleeve, protective, rubber hose
48 60028649 Hose, rubber
49 B230103001931 Hose, rubber
50 60025954 Hose, rubber
51 11573129 Seat, connector, hose, rubber
52 60212494 Hose, rubber
53 12736883 Plate, support
54 A210111000038 Bolt
62 B229900005270 Connector, pipe
71 B220401000479 Valve, one-way
72 B210780000055 Connector, pipe
82 B210399000002 Screw plug, VSTI16x1.5EDA3C
84 B210780001286 Connector, hose, GE10LM12x1.5EDOMDA3C
86 B210780000636 Connector, hose, EW10LOMDA3C
87 10781530 Flange
88 B210780000056 Connector, flange
92 11765669 Threading tube GP
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
