Каталог запасных частей к технике: SANY SY5320THB 470C-8S. 12827887 Pipeline, hydraulic, main system
11
14
21
22
27
39
39
39
46
51
52
52
53
54
55
56
57
58
59
79
81
81
82
82
83
84
84
85
86
87
88
89
90
91
92
93
94
94
95
96
97
98
99
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 11 | A820205001923 | Plug, screw | |
| 14 | B230101000244 | O-ring | |
| 21 | B210780000005 | Flange, SAE | |
| 22 | 21005036 | Screw | |
| 27 | A220401000753 | Valve, ball | |
| 39 | A210609000134 | O-ring | |
| 46 | B230103003967 | Hose, rubber | |
| 51 | B230103003916 | Hose, rubber | |
| 52 | A210204000216 | Screw | |
| 53 | 11766505 | Flange, rod side chamber, right oil cylinder | |
| 54 | A230101000264 | O-ring | |
| 55 | 60090922 | Screw | |
| 56 | 11703601 | Flange, rod side chamber, right | |
| 57 | A210204000469 | Screw | |
| 58 | 60014674 | Body, pipe clamp | |
| 59 | 60211051 | Hose, rubber | |
| 79 | B230103003875 | Hose, rubber | |
| 81 | B210780000200 | Connector, pipe | |
| 82 | 21050783 | Connector, pipe | |
| 83 | B230103005752 | Hose, rubber | |
| 84 | 60023941 | Body, clamp | |
| 85 | 12757804 | Pipe, steel, oil, return, air cooling | |
| 86 | B230103005121 | Hose, rubber | |
| 87 | B210780001733 | Connector, pipe | |
| 88 | B230103000427 | Hose, rubber | |
| 89 | A210609000166 | O-ring | |
| 90 | A210204000250 | Screw | |
| 91 | 11737448 | Valve, connecting, oil cylinder | |
| 92 | 12827368 | Pipe, steel | |
| 93 | 21008727 | Fitting, pipe | |
| 94 | B210780001404 | Connector, pipe | |
| 95 | 12632799 | Oil return flange components | |
| 96 | 60196689 | Valve, one-way | |
| 97 | B210780000631 | Connector, hose, ET10LOMDA3C | |
| 98 | A832313030000 | Pipe, rubber | |
| 99 | B230103000474 | Hose, rubber | |
| 100 | 60161194 | Hose, rubber | |
| 101 | 11300142 | Cover, waterproof, valve GP, control, oil cylinder | |
| 102 | B230103003026 | Hose, rubber | |
| 103 | 60014675 | Body, pipe clamp | |
| 104 | B230103004202 | Hose, rubber | |
| 105 | B230103003857 | Hose, rubber | |
| 106 | A810201020910 | Pressure gauge valve group | |
| 107 | A210204000146 | Screw, M8x16 GB70.1 | |
| 108 | B250202000006 | Gauge, pressure | |
| 109 | 60209257 | Pipe, pressure measuring | |
| 110 | 11703604 | Flange, rod side chamber, left | |
| 111 | A210609000060 | O-ring | |
| 112 | A820205000005 | Connector, pipe, U-shaped | |
| 113 | B220400000101 | Valve, one-way | |
| 114 | B210780000164 | Plug, screw | |
| 115 | B210399000003 | Screw plug, VSTI10x1EDA3C | |
| 116 | 11766437 | Flange, rod side chamber, left oil cylinder |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
