Каталог запасных частей к технике: SANY SY5320THB 470C-8S. 12772657 Hydraulic system, outrigger

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
3
3
3
3
3
4
5
6
7
7
7
7
7
8
9
10
11
13
14
15
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
30
31
32
33
34
34
35
38
38
41
42
43
58
63
64
65
66
68
68
69
70
72
73
74
75
76
77
78
82
82
83
84
85
86
Позиция на иллюстрации Заводской номер детали Название детали
1 12741309 Pipe, oil
2 10453513 Pipe, oil
3 B210780000037 Connector, hose, GE12LMEDOMDA3C
4 60056150 Lock, hydraulic, outrigger, rear
5 B230103000331 Hose, rubber
6 B230103004635 Hose, rubber
7 B210780000024 Connector, hose, EW12LOMDA3C
8 60014671 Body, clamp
9 11863416 Pipe, oil
10 11863441 Pipe, oil
11 11885463 Pipe, oil
13 B230103003867 Hose, rubber
14 B230103003866 Hose, rubber
15 B230103003864 Hose, rubber
16 60019586 Hose, rubber
17 60004165 Lock, hydraulic, telescopic cylinder
18 B210780000036 Connector, pipe
19 B230103000089 Hose
20 10984687 Wheel, guide
21 12742193 Pipe, oil
22 B210780000016 Connector, hose, EL12LOMDA3C
23 10922832 Pipe, oil
24 10922815 Pipe, oil
25 11350983 Plate, connector, four-hole
26 B210780000115 Connector, pipe
27 60126767 Hose, rubber, triple
28 B210780000176 Connector, pipe
29 11144485 Plate, mounting, disc, bobbing
30 B210780000847 Connector, hose, GE12LR1/4EDOMDA3C
31 60031865 Disc, bobbing
32 10939950 Pipe, oil
33 11694588 Pipe, oil
34 A210204000130 Screw
35 A210401000019 Washer
38 10888719 Connector, pipe
41 11885526 Pipe, oil
42 11885550 Pipe, oil
43 11885576 Pipe, oil
58 60031864 Disc, bobbing
63 12768252 Valve GP, control, outrigger
64 11142092 Plate, fixed, steel wire, drum axis
65 11350921 Plate, connector, six-hole
66 A820301010402 Bolt, articulated
68 B210399000002 Screw plug, VSTI16x1.5EDA3C
69 B210780000088 Plug
70 B210334000011 Nut
72 12728894 Pipe, oil
73 12728908 Pipe, oil
74 12740291 Pipe, oil
75 12740330 Pipe, oil
76 12730322 Pipe, oil
77 12730309 Pipe, oil
78 60014672 Body, clamp
82 60113023 Sleeve, protective, hose, rubber
83 24002192 Screw
84 24000637 Washer
85 B230101000417 O-ring
86 12585103 Plate, bent, folded
