Каталог запасных частей к технике: SANY SY5320THB 470C-8S. 12563916 Hydraulic system, boom

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
25
25
25
25
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
44
44
44
44
44
45
46
47
47
47
47
53
53
53
53
53
55
55
55
55
55
55
58
58
58
58
65
65
67
67
67
67
68
72
73
74
75
75
77
81
81
81
84
89
91
92
94
94
100
100
100
100
105
105
106
106
106
108
109
Позиция на иллюстрации Заводской номер детали Название детали
25 B230103003885 Hose, rubber
30 12839743 Pipe, oil
31 12839745 Pipe, oil
32 12839747 Pipe, oil
33 12839749 Pipe, oil
34 12839751 Pipe, oil
35 12839753 Pipe, oil
36 12839755 Pipe, oil
37 12839757 Pipe, oil
38 12839759 Pipe, oil
39 B230103003881 Hose, rubber
40 12841233 Pipe, oil
41 12841235 Pipe, oil
42 12841237 Pipe, oil
43 12841239 Pipe, oil
44 B210780000736 Connector, pipe
45 12841241 Pipe, oil
46 12841243 Pipe, oil
47 60159754 Valve, balanced
53 A820205000223 Connector, pipe
55 B230101000375 O-ring
58 60061670 valve, damper, one-way
65 B210780000099 Connector, pipe
67 B210780000024 Connector, hose, EW12LOMDA3C
68 B210780000037 Connector, hose, GE12LMEDOMDA3C
72 A810201024337 Pipe, oil
73 12738694 Pipe, oil
74 12733458 Pipe, oil
75 12734372 Pipe, oil
77 60210214 Hose, rubber
81 B210780000015 Connector, hose, EL10LOMDA3C
84 12734240 Pipe, oil
89 11805687 Sleeve, protective, rubber hose, plastic
91 60186836 Connector, filter
92 60186837 Connector, filter
94 B230103003877 Hose, rubber
100 B210780000177 Connector, hose, GE10LR3/8EDOMDA3C
105 12638409 Clamp
106 12638380 Clamp
108 60196984 Hoop
109 60196981 Hoop
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
