Каталог запасных частей к технике: SANY SY5250GJB6C. 11050114 Carnage assembly

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
11
12
12
12
12
13
13
13
13
14
14
15
15
16
16
16
16
17
17
18
18
19
19
20
21
22
23
24
25
26
27
Позиция на иллюстрации Заводской номер детали Название детали
1 10781644 Crossbeam, front
2 А210319000023 Nut
3 11071586 Seat, , drawing hook
4 А210110000281 Bolt
5 А210111000054 Bolt
6 11050112 Longitudinal beam of frame
7 А820402000313 Bracket, fixed end, suspension, front
8 А820101026056 Sheet, stiffening, left, front
9 А820402000314 Bracket, rear, shackle, suspension, front
10 11459190 Crossbeam GP, middle
11 А210319000019 Nut
11 А210319000019 Nut
12 А820101026772 Board, thrust
12 А820101026772 Board, thrust
13 А210111000243 Bolt
13 А210111000243 Bolt
14 А810410000645 Bracket, connection
14 А810410000645 Bracket, connection
15 А210111000055 Bolt
15 А210111000055 Bolt
16 11647517 Crossbeam GP, backrest beam, front
16 11647517 Crossbeam GP, backrest beam, front
17 11267302 Crossbeam GP, backrest beam, rear
17 11267302 Crossbeam GP, backrest beam, rear
18 А820101026042 Crossbeam, tail
18 А820101026042 Crossbeam, tail
19 11128448 Beam GP, stiffening, hook, towing
19 11128448 Beam GP, stiffening, hook, towing
20 А810422002516 Bracket, connection, lower
21 А820301990120 Lockpin
22 10073933 Bracket, hook, towing, rear
23 А820301016835 Pin, hook, towing
24 10021426 Crossbeam, rear
25 11050113 Longitudinal beam of frame (right
26 А820101026057 Plate, stiffening, right, front
27 А810401100570 Column crossbeam GP
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
