Каталог запасных частей к технике: SANY SY335C8. 60046519 Camshaft & Valve Mechanism
1
2
2
3
3
4
5
6
7
7
7
7
8
8
8
8
9
10
11
11
12
12
13
13
14
14
14
14
14
14
14
14
15
15
16
16
17
17
17
17
18
18
18
18
19
19
19
19
20
21
22
23
24
24
25
25
26
27
28
29
30
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B229900004431 | Camshaft | |
| 2 | B229900004349 | Valve, Inlet | |
| 3 | B229900004386 | Valve, Exhaust | |
| 4 | B229900004949 | Bolt | |
| 5 | B229900004632 | Washer | |
| 6 | B221801000032 | Gear | |
| 7 | B229900005048 | Bearing, Upper | |
| 8 | B229900005051 | Bearing, Lower | |
| 9 | B229900005058 | Dowel | |
| 10 | B229900004440 | Shaft, Rocker Arm | |
| 11 | B229900004792 | Bolt | |
| 12 | B229900004824 | Nut | |
| 13 | B229900004442 | Support, Rocker Arm | |
| 14 | B222200000044 | Locker | |
| 15 | B229900004749 | Spring, Valve | |
| 16 | B229900005021 | Spring, Valve | |
| 17 | B229900005041 | Seat, Valve Spring | |
| 18 | B229900005042 | Seat, Valve Spring | |
| 19 | B229900004395 | Washer | |
| 20 | B229900004855 | Bolt | |
| 21 | B229900004945 | Bolt | |
| 22 | B229900004437 | Rocker Arm | |
| 23 | B229900004438 | Rocker Arm | |
| 24 | B229900005070 | Screw | |
| 25 | B229900004795 | Nut | |
| 26 | B229900005076 | Bracket | |
| 27 | B229900005075 | Spring | |
| 28 | B229900004943 | Bolt | |
| 29 | B229900004229 | Gear Ring, Idler | |
| 30 | B229900004258 | Cover |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
