Каталог запасных частей к технике: SANY SY335C8. 11454048 Pipeline, main, hydraulic

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
25
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
98
99
100
101
Позиция на иллюстрации Заводской номер детали Название детали
1 A229900004566 Clamp, pipe
2 A810201024312 Pipe, oil inlet
3 A810201024313 Pipe, oil outlet
4 B210780000693 Flange, SAE
5 A810201024318 Hose AS, oil outlet
6 A810201024317 Hose AS, oil inlet
7 11213517 Pipe, oil return, main
8 A810201066621 Pipe As, left travel
9 A810201066620 Pipe As, left travel
10 11131553 Tube As, arm, lower
11 Tube As, swing, lower Tube As, swing, lower
12 Tube AS, swing, upper Tube AS, swing, upper
13 11202999 Tube AS, arm, upper
14 A820301013877 U-bolt
15 A210307000001 Nut
16 A210404000004 Washer, 12 GB96.1
17 Plate Plate
18 60068054 Hose, rubber
19 B230101000050 O-ring
20 A820205002644 Plug
21 Reducer GP Reducer GP
22 Hose, rubber Hose, rubber
23 Flange, split Flange, split
24 A210401000001 Washer
25 A210204000354 Screw
26 A820205001355 Connector, extended
27 A820205001356 Connector
28 A210609000136 O-ring
29 B230103003077 Hose, rubber
30 A210204000462 Screw
31 A210401000002 Washer
32 A820101310467 Clamp, pipe
33 11124936 Tube AS, boom, upper
34 11124934 Tube As, boom, lower
35 A210204000338 Screw
36 A210204000215 Screw
37 A210405000011 Washer
38 B230101000456 O-ring
39 11124928 Clamp, pipe
40 11124929 Tube AS, boom, upper
41 11124932 Tube As, boom, lower
42 B230103003073 Hose, rubber
43 B230103003072 Hose, rubber
44 11220261 Tube AS, bucket, upper
45 11220262 Tube AS, bucket, lower
46 A239900000066 Bandage, nylon
47 10514225 Plug
48 A820203000983 Flange
49 11490962 Pipe As, right travel
50 11491348 Pipe As, right travel
51 A810201010292 Tank, hydraulic
52 B230101000445 O-ring
53 A810201024112 Pipe, oil return
54 A810201024464 Pipe, oil return
55 A210609000003 O-ring
56 11216198 Pipe, oil suction, fuel tank
57 A210204000206 Screw
58 A210404000008 Washer
59 A210111000263 Bolt
60 A210855000001 Hoop
61 A820606030534 Hose, oil suction
62 B240600000116 Sensor, pressure
63 A820205001513 Connector
64 B230101000047 O-ring
65 B230101000356 O-ring
66 A820205000942 Connector
67 A832713060000 Hose, rubber
68 B230101000039 Seal, O-ring
69 11216188 Pipe, oil suction, main pump
70 A210405000003 Washer
71 A210204000198 Screw
72 B220301000357 Pump, plunger
73 B210780000004 Flange, split
74 60037639 Hose, rubber
75 A210204000348 Screw
76 A210401000006 Washer
77 10483031 Pipe, bypass, oil return
78 A210111000321 Bolt
79 A820301017131 U-bolt
80 10456336 Bracket, main valve
81 B220401000190 Valve, main control
82 B230101000366 O-ring
83 10482860 Adapter
84 A210204000031 Screw
85 A820203001650 Flange
86 60037638 Hose, rubber
87 B210780000244 FLANGE - HALF
88 A210204000361 Screw
89 B220401000590 Valve, check
90 B220401000589 Valve, check
91 A210401000008 Washer
92 60047044 Hose, rubber
93 60068053 Hose, rubber
94 60068055 Hose, rubber
95 A210204000353 SCREW
96 A210401000003 Washer
97 11530825 Plate
98 B230103004209 Hose, rubber
99 60077167 Hose, rubber
100 A210204000355 Screw
101 11328553 Foam
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
