Каталог запасных частей к технике: SANY SY335C8. 11165195 Painting

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Позиция на иллюстрации Заводской номер детали Название детали
1 A820699000793 Decal, counterweight
2 A820699001016 Decal, warning, counterweight
3 10220820 Decal, right, rear
4 10233839 Decal, right, middle
5 10233853 Decal, right middle, strip
6 10220830 Decal, right, front
7 10233851 Decal, right, front
8 A820699000746 Decal, service information
9 10251978 Nameplate
10 A210510000007 Rivet
11 10220811 Decal, boom, side
12 A820699000747 Decal, boom
13 A820101990552 Film - Identification
14 A820601990934 Decal, tie-down, shipment
15 A820601990968 Decal, warning, tensioner
16 10232575 Decal, center of gravity
17 A820601990963 Decal, warning, arm
18 10220816 Decal, left front, strip
19 10220817 Decal, right, front
20 10233828 Decal, left front, machine body
21 10220833 Decal, logo
22 10220834 Radiator
23 10220815 Decal, left rear, machine body
24 A820603000251 Decal, counterweight
25 11165169 Film - Machine Model
26 A820601991039 Decal
27 A820601991037 Decal
28 A820601990926 Decal, warning, falling
29 A820699000369 Anti-skid, long
30 A820601990973 Decal, warning, engine hood
31 A820699001017 Decal, warning, belt safety
32 A820600000002 Decal, warning, fan
33 A820699000948 Decal, warning, anti-spray
34 A820699001023 Decal, warning, no-sitting
35 11471948 Shim, adjusting, counterweight
36 11471950 Shim, adjusting, counterweight
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
