Каталог запасных частей к технике: SANY SY135C8. B229900002718 Reducer GP
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | B229900005915 | Shaft, drive, swing reducer | |
| 2 | B229900005914 | Cover, seal, swing reducer | |
| 3 | B221500000591 | Bearing, roller, swing reducer | |
| 4 | 60038440 | Housing | |
| 5 | 60008609 | Plug | |
| 6 | 60038620 | Pin | |
| 7 | 60038547 | Nameplate | |
| 8 | B229900005907 | Ring, retaining, swing reducer | |
| 9 | B221801000057 | Gear, planetary, swing reducer | |
| 10 | B229900005918 | Roll, pin, swing reducer | |
| 11 | 60008610 | Fitting, grease | |
| 12 | 60038163 | Plug | |
| 13 | B230101002046 | Seal, oil, swing reducer frame | |
| 14 | B221500000592 | Bearing, roller, swing reducer | |
| 15 | 60038871 | Ring, stop | |
| 16 | B229900005919 | Pipe, oil scale, swing reducer | |
| 17 | B229900000269 | Indicator, oil | |
| 18 | 60038261 | Pin, spring | |
| 19 | B229900005905 | Ring, retaining, swing reducer | |
| 20 | B221801000054 | Gear, sun, swing reducer | |
| 21 | 60038625 | Carrier, planetary | |
| 22 | B221801000055 | Gear, sun, swing reducer | |
| 23 | 60038624 | Carrier, planetary | |
| 24 | B229900005906 | Ring, retaining, swing reducer | |
| 25 | B221801000056 | Gear, planetary, swing reducer | |
| 26 | B229900005916 | Nut, lock, swing reducer | |
| 27 | 60038603 | Washer - Thrust | |
| 28 | B229900005522 | Ring, gear | |
| 29 | 60038870 | Ring, stop | |
| 30 | 60038451 | Screw, hex |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
