Каталог запасных частей к технике: SANY STC250S5. 12171292 Get-on multi-way valve

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Позиция на иллюстрации Заводской номер детали Название детали
1 11259975 Cover, end, front
2 60008433 O-ring
3 A210609000317 O-ring
4 12070328 2-bit and 2-passage Valve core
5 11987696 2-bit and 2-passage Spring
6 11987698 2-bit and 2-passage Spring
7 12051160 Upper cover plate
8 A210205000002 Screw
9 11259978 Plug, valve, compensation
10 11259977 Spring, compensation
11 11259976 Core, valve, compensation
12 11259981 Rod, damping
13 A210609000051 O-ring
14 12000907 Check Valve core STC250.4.3.1-20
15 11987646 spring
16 12070325 Valve block head STC250.4.3.1-16
17 A210609000099 O-ring
18 A210609000032 O-ring
19 11259982 Plug, installation, plug-in
20 60024957 Main spillover valve
21 A229900002606 Plug
22 12000527 Cutoff valve core
23 12019829 Pressure cutoff valve block
24 11846856 Cutoff valve spring
25 12070209 Spring valve plug
26 11259970 Plug, shuttle valve, confluent valve
27 11259980 Seat, valve, shuttle
28 A210661000016 Ball, steel
29 11259754 Spring, valve, flow, three-way
30 A210609000046 O-ring
31 11259752 Core, valve, flow, three-way
32 60024941 Valve, overload
33 11259987 Plug, valve
34 11259983 Cover, end, rear
35 60024952 Main spillover valve
36 11260070 Rod, valve, flow, three-way
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
