Каталог запасных частей к технике: SANY STC250S5. 11232450 Device, brake system

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
Позиция на иллюстрации Заводской номер детали Название детали
1 A210770000597 Tee adaptor, clamp sleeve-type end
2 A220401000198 Valve, release, quick
3 A210770000393 Connector, pipe
4 A229900002973 Washer, seal
5 A210770000392 Connector, pipe
6 A210111000089 Bolt
7 A210401000017 Washer
8 A229900003250 Connector, right angle, bulkhead
9 A210338000000 Nut
10 A241400000011 Pipe, nylon
11 A229900003021 Bushing
12 A210710000004 Sleeve, clip
13 A210306000012 Nut
14 A210405000007 Washer
15 A210307000012 Nut
16 A210111000097 Bolt
17 A229900003130 Hose, brake
18 A229900003037 Connector, measuring
19 11343921 Tee, pressure measuring
20 A229900002971 Washer, seal
21 A229900003033 Connector, tee
22 A229900003038 Elbow, right angle
23 A229900003249 Connector, right angle
44 60128949 Electromagnetic valve group
45 A820199003120 Joint block
46 A229900003040 Joint, right angle, arresting cone
47 A229900003045 Joint, right angle, adjustable
48 A229900005691 Hose gp, high temperature
49 A229900003350 Body, connector, through, clamp end
50 A210338000001 Nut
51 A820101330953 Bracket, front, hose, high-temp
52 10341557 Tube GP, steel, exhaust, air compressor
53 10379884 Joint, straight, end
54 A241400000013 Pipe, nylon
55 A210710000002 Sleeve, clip
56 A210306000007 Nut
57 A229900008569 Bushing
58 10594680 Adaptor, snap sleeve-type, straight
59 60062703 Silencer
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
