Каталог запасных частей к технике: SANY STC250S5. 11230009 Electrical system, chassis

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
Позиция на иллюстрации Заводской номер детали Название детали
6 B249900001345 Controller, ABS
7 12112495 ABS harness
8 60006879 Rocker switch
9 B249900000090 Horn 3CA-004-811-02
10 A820101331137 Bracket, horn, electric
11 A210111000089 Bolt
12 A210319000004 Nut
13 A210405000007 Washer
14 A240500000076 Air horn assembly
15 A810201058463 Wire, copper, woven
16 A249900000823 Sleeve, protective, battery
17 12681015 ECU HarnessSYM5304J3.8.5B
18 60125384 Switch, power supply
19 A820606010864 Ring, conduit
20 A210111000027 Bolt
21 60013322 Battery Terminal As - Positive
22 60072191 Power cord
23 A810201058462 Line, power supply
24 10957738 Storage battery & tank body assembly GP
25 60012783 Line, power
26 A249900001417 Box, control, master switch, power
27 10212064 Bracket, installation, control box
28 A820606010865 Coil, through
29 60072192 Power cord
30 60150275 Power supply line
31 60150276 Power Supply Line
32 60013321 Battery Terminal As - Negative
33 12397360 Null SYM5304J.8.4
34 60072876 Baroceptor
35 11343921 Tee, pressure measuring
36 A229900003257 Connector, spacer
37 60125826 Locating clamp, harness
38 60125827 Locating clamp, harness
39 60111214 Ring, through rope, rubber
40 A240600000139 Sensor, liquid level
41 A210210000003 Screw
42 A210401000015 Washer
43 A210404000010 Washer
44 12397351 Null SYM5304J.8.3
45 A810201058458 Cable, gearbox
46 60188923 Outrigger throttle switch assembly
47 A249900000823 Sleeve, protective, battery
48 10786273 Tee joint, control, gearbox
49 60034466 Sensor, pressure
50 12681057 50ton chassiscluster assem SYM5424J3.8.2B
51 60060804 Speed odometer sensor
52 10230323 Harness, preheating control
53 60072877 Switch, brake lamp
54 12681018 Rear finishing wire SYM5304J3.8.6B
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
