Каталог запасных частей к технике: SANY STC250H. A220600000038 Rear bridge GP

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
Позиция на иллюстрации Заводской номер детали Название детали
1 A229900006746 Bolt, half shaft , rear axle
2 A229900006753 Semi axis, left
3 A229900006743 Gasket, semi axis
4 A230101000354 Semi axis oil seal assembly
5 A229900008706 Plug, screw
6 A229900008673 Plug, screw, oil drain
7 A229900006752 Semi axis, right
8 A229900008687 Bolt,differential bearing cover
9 A221500000378 Plate
10 A229900008710 Differential, bearing
11 A229900008707 Differential, right shell
12 A221801000253 Gasket, semi-shaft gear
13 A221801000251 Gear, semi-shaft
14 A229900008694 Differential, cross shaft
15 A221801000261 Gear, planetary
16 A221801000256 Gasket, planet gear
17 A221500000374 Main gear, guide bearing
18 A221500000380 Bearing, tapered roller
19 A229900008675 Spacer bushing
20 A221500000381 Bearing, tapered roller
21 A229900008670 Shim, adjustment, bearing seat
22 A221805000037 Oil seal, drive bevel gear
23 A221805000038 Bearing house, drive bevel gear
24 A220800000158 Housing, main reducer
25 A220800000156 Bolt
26 A229900008731 Screw plug, filler well
27 A220800000155 Bolt,fastening main reducer
28 A221805000042 Flange, drive bevel gear
29 A229900008686 Nut
30 A221500000377 Ring, adjusting, differential bearing
31 A229900008712 Differential, left shell
32 A229900008689 Bolt,fastening differential shell
33 A229900008688 Bolt,driven gear & differential
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
