Каталог запасных частей к технике: SANY SDCY90K6C. 11742235 System, brake and steering

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
Позиция на иллюстрации Заводской номер детали Название детали
70 B210780000052 Connector, pipe
71 B210780000838 Connector, pipe
72 B230103001528 Hose
73 B210780000184 Connector, hose, GE18LR3/4EDOMDA3C
74 21032677 Tubing, rubber
75 B210780000232 Connector, hose, GE12LM14x1.5EDOMDA3C
76 B229900001996 Radiator Y360x210x420-10Q/SY015028
77 A210111000089 Bolt
78 A222100000281 Oil return filter QU-A100x10P
79 A210111000343 Bolt
80 A820501004250 Joint body RSC45.2.3-6
81 A210434000018 Washer
82 11551450 Block, valve, sequence
83 A220401000259 Valve, sequence
84 A210204000009 Screw
85 B230103001233 Hose
86 B230103005260 Pipe
87 21003891 Hose, rubber
88 2848515 Group, priority valve
89 B230103007325 Hose, rubber
90 B230103004310 Hose, rubber
91 A239900000066 Bandage, nylon
92 A230200000363 Sheath, plastic
93 A230200000490 Plastic protective sleeve 21
94 A230200000359 Sleeve, protection, spiral, flexible, hydraulic
95 B230103005739 Hose, rubber
96 21026929 Hose, rubber
97 B210780000024 Connector, hose, EW12LOMDA3C
98 B210780000071 Connector, tubing
99 60019147 Hose, rubber
100 B210780001748 Connector, pressure measuring
101 12301919 Group, check valve
102 21005024 Screw
103 B210780001241 Pipe joint EW30SOMDA3C
104 B210780000029 Connector, pipe
105 B210780000072 Connector, tubing
106 B230103003412 Hose, rubber
107 B230103001087 Hose, rubber
108 B230103000378 Hose, rubber
109 B230103002447 Hose
110 B210780000047 Connector, pipe
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
