Каталог запасных частей к технике: SANY SDCY90K6C. 11742235 System, brake and steering

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
Позиция на иллюстрации Заводской номер детали Название детали
1 B230103008321 Hose, rubber
2 B210780000890 Flange, slot
3 B230101000270 O-ring, 56.7x3.53 AS568-228 N70
4 B230103008467 Hose, rubber
5 10145253 Component, flange
6 B210780000741 Flange, split, FHS38A3CX
7 A210204000343 SCREW
8 B230103000466 Hose
9 B230101000300 O-ring
10 A820199003396 Flange 2, oil outlet, gear pump
11 B230103001556 Hose, rubber
12 B230103000773 Hose, rubber
13 B210780001048 Pipe joint GE10L7/16UNFOMDA3C
14 B230103000123 Hose, rubber
15 B210780000636 Connector, hose, EW10LOMDA3C
16 60019594 Hose, rubber
17 A810201062430 Brake control valve group RSC45.2.3.15
18 A210111000293 Bolt
19 A210401000017 Washer
20 B220401001021 Pump, gear, double
21 A229900005971 Bolt 1/2"-13UNx45 10.9 galvanization
22 A820199003395 Flange, oil outlet, gear pump
23 A210609000142 O-ring
24 A210204000215 Screw
25 B210780000249 Sae flange
26 A210204000206 Screw
27 B230101000348 O-ring
28 B230103008547 Hose, rubber
29 B210780000115 Connector, pipe
30 B210780000157 Connector, pipe
31 B210780000647 Connector, pipe
32 B230103000395 Hose, rubber
33 B230103007337 Hose, rubber
34 A810201024583 Tubing, steel
35 B230103000399 Hose, rubber
36 B230103003290 Hose, rubber
37 A819700001629 Cooling switching valve group RSC45.2.3.16
38 B230103004055 Hose 1SN10-DKOL-DKOL90-1400Q/SY1102
39 A810201069499 Drawing, assembly, component, brake valve
40 B230103000398 Hose, rubber
41 A810201024584 Tubing, steel
42 B230103000396 Hose, rubber, 2SN16-DKOL-DKOL90-750Q/SY1102
43 B230103003026 Hose, rubber
44 B230103000376 Hose, rubber
45 B210770000084 Connector, pressure measuring
46 10118813 Flange
47 60185448 Group, pump, double
48 10118785 Flange
49 B230103000557 Hose, rubber
50 B210780001153 Connector, pipe
51 21018381 Hose, rubber
52 60209096 Muff
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
