Каталог запасных частей к технике: SANY SDCY90K6C. 10126062 Frame

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
3
4
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
Позиция на иллюстрации Заводской номер детали Название детали
1 11337060 Body, frame
2 10118544 Plate, mudguard, front, right
3 A210111000027 Bolt
4 A210401000001 Washer
5 A210405000011 Washer
6 A210110000324 Bolt
7 A210307000040 Nut
8 A210405000003 Washer
9 A210401000004 Washer
10 11338711 Mudguard, rear, (left side)
11 11338720 Mudguard, rear, (right side)
12 A210307000029 Nut
13 A210405000008 Washer
14 A210401000006 Washer
15 A222000000066 Vibration damper ZMD170x180-00
16 A210110000463 Bolt
17 A210401000012 Washer, 36 GB93
18 A820102010533 Washer RSC45.8-17
19 10944625 Counterweight, lower
20 10259476 Counterweight, upper
21 10947629 Plate, support, left
22 10182064 Rearview mirror SDCY90K7.2.11
23 10975487 Sealing plate
24 A210204000162 Screw
25 A210405000007 Washer
26 A210401000017 Washer
27 10201511 Rearview mirror SDCY90K7.2.13
28 A210111000038 Bolt
29 A210401000002 Washer
30 A210404000004 Washer, 12 GB96.1
31 10182487 Plate, connection, straight
32 10182493 Plate, connection, left
33 A221500000323 Bearing, sliding
34 23904816 Screw
35 10020274 Plate, reinforced
36 10947630 Plate, bracket, right
37 10449033 Cover plate
38 10132126 Mudguard, front, left
39 10049665 Antiskid paste RSC45.3-9
40 11078697 Bracket, exhaust pipe
41 A210111000040 Bolt
42 10612049 Deflector, shaft end
43 A210111000230 Bolt
44 11297731 Bracket, lamp, front
45 A210202000015 Screw
46 A210307000014 Nut
47 11006387 Tail light mounting plate SDCY90K7.2-20
48 A210307000017 Nut
49 10262314 Diagram, assembly, support, upper
50 11087254 Kettle
51 A239900000531 Coating
52 10995855 Pad adjustment
53 A820101010676 Single-pipe clamp 6
54 10480997 Mounting sleeve RSC45M.3-6
55 11339493 Sleeve, protection
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
